Запчасти Case IH 1670 (2-16) - ETHER STARTING, DTI466C ENGINE (01) - ENGINE

Схема запчастей Case IH 1670 - (2-16) - ETHER STARTING, DTI466C ENGINE (01) - ENGINE
9
5
1
7
2
3
8
4
6
5

Артикул

Название

Примечание

Количество

1

REF

INSTRUCTION

FLUID - ether starting (12 ounce can)

1шт.

2

121842C91

SOLENOID SWITCH

SOLENOID ASSEMBLY - ether injection, Includes: Ref. 3 and 4

1шт.

3

395686R1

GASKET

- injector solenoid (0.240 inch ID) (If equipped)

1шт.

3

1963571C1

GASKET

GASKET - injector solenoid (0.600 inch ID) (If equipped)

1шт.

4

121851C1

RETAINER

BAIL - injector

1шт.

5

289970C91

FITTING

ELBOW - 90 degree, 1/8-27 thread x 1/8 tube

2шт.

6

NSS

NOT SOLD SEPARAT

TUBE - solenoid to manifold, 50 inch long (Order 1954063C2, Serial Range: cut-length)

1шт.

7

269635R91

NOZZLE CAP

NOZZLE - starting fluid

1шт.

8

161945C1

SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1"

- slotted truss head, 5/16 NC x 1 inch

2шт.

9

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

- hex flange lock, 5/16 inch NC

2шт.

Выбрано товаров: 10
