Запчасти Case IH AFX8010 (A.40.A.89) - ELECTRICS ON HITCH A - Distribution Systems

84081529

HITCH

Kit

1шт.

For EU Only

1шт.

84081530

HITCH

Kit

1шт.

For NA Only

1шт.

1

86585708

SCREW,Pan Hd, M4 x 43.25mm, Cl 4.8

3шт.

For EU Only

1шт.

1

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

Replaced 120104

3шт.

For NA Only

1шт.

1

120104

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

1шт.

For EU Only

1шт.

2

398224

MULTIPOLE CONNECTOR,7 Pin

1шт.

For EU Only

1шт.

2

265927

POWER SOCKET

1шт.

For NA Only

1шт.

3

84432533

PLATE

1шт.

For EU Only

1шт.

3

86837475

BRACKET

1шт.

For NA Only

1шт.

4

9706748

CLAMP,15.9mm, Coat, 8.7mm Bolt Hole, P Type

2шт.

5

86588450

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

1шт.

For EU Only

1шт.

6

89824840

WASHER,4.3mm ID x 9mm OD x 0.8mm Thk

3шт.

For EU Only

1шт.

6

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

1шт.

For NA Only

1шт.

6

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

1шт.

For EU Only

1шт.

7

385681

NUT,M4 x 0.7, Cl 8

3шт.

For EU Only

1шт.

7

9706690

NUT,M8 x 1.25, Cl 8

3шт.

For NA Only

1шт.

7

9706690

NUT,M8 x 1.25, Cl 8

1шт.

For EU Only

1шт.

8

86566989

CABLE TIE,208mm L

CABLE STRAP

7шт.

9

86604178

WIRE HARNESS

Hitch

1шт.

10

102043

GROMMET,19.05mm ID x 34.925mm OD x 11.11mm Thk

1шт.

For EU Only

1шт.
