Запчасти Case IH AFX8010 (A.40.A.85[1]) - LIGHTS, SIDE MARKER, HEADER - EU A - Distribution Systems

1

84077733

BRACKET

1шт.

2

449531

POSITION LAMP,Red

Side Marker

2шт.

3

335315

GROMMET

2шт.

4

84432334

WIRE HARNESS

Side Marker Lights

1шт.

5

86566989

CABLE TIE,208mm L

CABLE STRAP

9шт.

6

84432804

SUPPORT

1шт.

7

120100

BOLT,M6 x 20mm, Cl 8.8

4шт.

8

86588450

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

4шт.

9

322357

BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk

4шт.

10

353308

NUT,M6 x 1.0, Cl 8

4шт.
