Запчасти Case IH AFX8010 (K.90.E.70) - STONE TRAP AND ROLLER K - Crop Processing

1

86995743

SUMP

1шт.

2

86995744

HANDLE

1шт.

3

86999020

EYEBOLT,M12 x 237mm

2шт.

4

86995745

DOOR

1шт.

5

86995746

ROD

1шт.

6

86995747

TUBE,28.60mm OD x 90mm OAL

Stone Trap Door

2шт.

7

80754

COTTER PIN,3/16" OD x 1-1/2" OAL

2шт.

8

86995153

HANDLE

Grab

1шт.

9

140046

BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk

4шт.

10

9706685

NUT,M12 x 1.75, Cl 8

2шт.

11

100038

NUT,M12 x 1.75, Cl 8

2шт.

12

87284912

BEATER,Assembly

Was 87108963 - Includes Ref. 17

1шт.

13

87108966

KNIFE BLADE

Blade, Spiral - Beater

4шт.

13

87360866

KNIFE

Blade, Serrated Spiral - Beater

4шт.

14

86512446

CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8

28шт.

15

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

28шт.

16

100037

LOCK NUT,M10 x 1.5, Cl 8

28шт.

17

87109491

OIL SEAL

1шт.

18

87691657

PACKAGE,SERVICE

Kit, Serrated Spiral Blade; Includes: Ref. 13, 87360866 (4)

1шт.
