Запчасти Case IH AFX8010 (K.60.B.52[1]) - GRAIN ELEVATOR TENSIONER & CHAIN K - Crop Processing

1

87584827

CHAIN

Roller, Start Serial: HAJ105101

1шт.

2

87282471

BLADE

36шт.

3

25812

CONNECTING LINK

1шт.

4

87281911

ELEVATOR CHAIN,CA550HD, 145 Links x 41.4mm = 6003mm

Replaced 87281890, Replaced 87280487

1шт.

5

86998942

PIN

2шт.

6

86998941

SUPPORT

1шт.

6

87283177

SUPPORT

, Start Year: 09-FEB-04

1шт.

7

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

14шт.

8

120104

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

7шт.

9

9706690

NUT,M8 x 1.25, Cl 8

7шт.

10

140048

BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk

2шт.

11

825-1416

NUT,M16, Cl 8

2шт.

12

359211

BOLT,M16 x 2.0 x 150mm, Cl 8.8

1шт.

13

80755

COTTER PIN,1/8" OD x 1" L

2шт.

14

86574857

CONNECTING LINK

, Years: -09-FEB-04

1шт.

14

87282356

CONNECTING LINK

Includes: 87610182, Start Year: 09-FEB-04

1шт.

14

87610182

PIN,3.17mm OD

S-Pin; Services 87282356

1шт.

15

86999835

RIVET

1шт.

16

86575773

LINK CHAIN

Roller

1шт.

17

86995345

LINK,Chain

6шт.

18

87281918

LINK,550 HD, 3 Links x 41.4mm = 124.2mm

Blade Attachment

1шт.

19

87281909

LINK CHAIN

Attachment

1шт.

20

23442R1

PIN,2.36mm OD

"S" - For Ref. 14 and 17 - Not Shown

1шт.
