Запчасти Case IH AFX8010 (E.34.A.70[2]) - USER PLATFORM EXTENSION, LH E - Body and Structure

1

43138

BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8

3шт.

2

87106000

PLATFORM

1шт.

3

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

1шт.

4

100016

NUT,M10 x 1.5, Cl 8

1шт.

5

43151

BOLT,Hex, M12 x 20mm, Cl 8.8, Full Thd

1шт.

6

86511324

WASHER,13mm ID x 24mm OD x 2.5mm Thk

1шт.

7

140046

BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk

2шт.

8

9706685

NUT,M12 x 1.75, Cl 8

1шт.

9

43139

BOLT,M10 x 1.5 x 25mm, Cl 8.8

4шт.

10

86511323

WASHER,10.5mm ID x 20mm OD x 2mm Thk

5шт.

11

86615600

PLATE

2шт.

12

84989474

ROLLER

1шт.

13

86509596

BOLT,Hex, M10 x 160mm, Cl 8.8

1шт.

14

100037

LOCK NUT,M10 x 1.5, Cl 8

1шт.
