Запчасти Case IH AFX8010 (E.34.A[1]) - USER PLATFORM, RH E - Body and Structure

1

86999859

PLATFORM

1шт.

2

86999875

SUPPORT

, Years: -15-AUG-03

1шт.

3

86642692

STEP

, Years: -15-AUG-03

1шт.

4

86999866

HANDRAIL

1шт.

5

86625263

WASHER,9mm ID x 20mm OD x 1.6mm Thk

10шт.

6

86625255

WASHER,13.3mm ID x 24.5mm OD x 3mm Thk

, Years: -15-AUG-03

8шт.

7

86624176

WASHER,11mm ID x 20mm OD x 2mm Thk

, Years: -15-AUG-03

12шт.

7

86624176

WASHER,11mm ID x 20mm OD x 2mm Thk

, Start Year: 15-AUG-03

1шт.

8

9824642

BOLT,M12 x 1.75 x 42.68mm, Cl 10.9

, Years: -15-AUG-03

4шт.

9

337475

NUT,M12, Cl 10

, Years: -15-AUG-03

4шт.

10

829-1410

NUT,M10 x 1.5, Cl 10.9

, Years: -15-AUG-03

4шт.

11

86624978

BOLT,Hex, M10 x 35mm, Cl 10.9, Full Thd

8шт.

12

86625005

BOLT,Hex, M8 x 60mm, Cl 10.9

6шт.

13

43362

NUT,M8 x 1.25, Cl 10

4шт.

14

87281023

STEP

Access, Start Year: 15-AUG-03

1шт.

15

43138

BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8

, Start Year: 15-AUG-03

4шт.

16

100016

NUT,M10 x 1.5, Cl 8

, Start Year: 15-AUG-03

4шт.

17

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

, Start Year: 15-AUG-03

4шт.

18

86511323

WASHER,10.5mm ID x 20mm OD x 2mm Thk

, Start Year: 15-AUG-03

4шт.

19

87428462

SUPPORT

1шт.
