Запчасти Case IH AFX8010 (E.10.B[4]) - DOOR LOCK, STRAWHOOD, WINDROW - PIN HAJ105201NA/HAJ103201EU AND AFTER E - Body and Structure

1

87283107

TUBE,0.75" ID x 1.00" OD

1шт.

2

87283115

PLATE

Guide

1шт.

3

87283117

PLATE

Guide

2шт.

4

87283111

PLATE

Slide

1шт.

5

87283113

LOCKING PLATE

1шт.

6

9706703

CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 20mm, Cl 8.8, Full Thd

7шт.

7

86512446

CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8

1шт.

8

86511323

WASHER,10.5mm ID x 20mm OD x 2mm Thk

1шт.

9

100037

LOCK NUT,M10 x 1.5, Cl 8

1шт.

10

322357

BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk

7шт.

11

9706755

NUT,M6, Cl 8

7шт.

12

87283109

BRACKET

2шт.

13

308761

CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8

4шт.

14

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

4шт.

15

9706690

NUT,M8 x 1.25, Cl 8

4шт.

16

374891

CARRIAGE BOLT,Rnd Head, M6 x 1 x 25mm, Cl 8.8

1шт.

17

86588450

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

1шт.

18

353308

NUT,M6 x 1.0, Cl 8

1шт.

19

87283314

SPRING

Extension

1шт.
