Запчасти Case IH AFX8010 (02) - BELTS & CHAINS - LEFT SIDE A - Distribution Systems

1

86980546

V-BELT

Shoe Drive

1шт.

See Figure K.62.B.41 (1)

1шт.

1

87317063

V-BELT,3651mm Nominal Length x 22.33mm W

Shoe Drive

1шт.

See Figure K.62.B.41 (1)

1шт.

Enhanced Cleaning

1шт.

2

86517680

V-BELT,3 Rib, 3045mm Nominal Length

Beater Drive

1шт.

See Figure K.64.E.40 (2)

1шт.

3

87011585

V-BELT,2HB, 38.1mm W x 3254mm L, 2 Ribs

Unloading Drive

1шт.

See Figure K.72.B.40 (1)

1шт.

4

86975809

V-BELT,0.88" W x 1844.04mm Nominal Length

Bubble Up Drive, 86975809

1шт.

See Figure K.60.B.40 (1)

1шт.

5

86976208

V-BELT,3 Rib, 2720mm Nominal Length

Strawchopper Drive

1шт.

See Figure K.64.C.40 (2)

1шт.

3000 RPM

1шт.

5

87283315

V-BELT,16.00 mm W x 2690.00 mm L, 3 Ribs

Strawchopper Drive

1шт.

See Figure K.64.C.40 (2)

1шт.

2800 RPM

1шт.

6

86998066

CHAIN,60H, 284 Links x 19.05mm = 5410.2mm

Unloading Drive

1шт.

See Figure K.72.B.40 (2)

1шт.
