Запчасти Case IH 9010 (90.102.03[03]) - GUARDS, ENGINE - PIN HAJ202001 & AFTER - 8010 (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH 9010 - (90.102.03[03]) - GUARDS, ENGINE - PIN HAJ202001 & AFTER - 8010 (90) - PLATFORM, CAB, BODYWORK AND DECALS
27
21
18
36
32
2
34
31
49
22
4
32
12
17
21
9
21
10.304.09
8
36
21
23
14
36
21
21
38
45
23
23
21
46
7
10
1
21
21
25
22
30
38
37
36
-
36
21
22
38
11
33
41
26
13
22
39
21
44
6
22
23
21
43
20
33
20
21
23
42
29
36
21
5
21
21
23
29
21
33
35
16
36
36
36
26
23
23
47
24
21
22
50
3
23
21
31
21
21
38
40
28
28
19
15
43

Артикул

Название

Примечание

Количество

1

87581059

SUPPORT ASSY.

1шт.

2

87556589

COVER

1шт.

3

87717388

STEP

1шт.

4

87653826

HINGE

2шт.

5

87555598

COVER ASSY

Includes: Ref 49

1шт.

6

87555590

CHANNEL

1шт.

7

87380912

HANDRAIL

1шт.

8

87584090

SHEET ASSY.

1шт.

9

87582121

SHEET METAL

1шт.

10

87555594

SUPPORT ASSY.

1шт.

11

87109081

SUPPORT

1шт.

12

87281729

BUSHING

1шт.

13

87550271

SHEET

1шт.

14

87555716

CURTAIN

No Longer Used-- Remove and discard

1шт.

15

87676625

DEFLECTOR

1шт.

16

86975394

BUMPER

2шт.

17

86611329

SPRING

1шт.

18

86611330

PIN,16.56mm OD

1шт.

19

87913

LOCK PIN,3.17mm OD x 31.75mm L, Slotted

1шт.

20

140041

WASHER,M8 x 28mm OD x 3mm Thk

5шт.

21

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

61шт.

22

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

11шт.

23

9706690

NUT,M8 x 1.25, Cl 8

22шт.

24

86580795

SPACER

1шт.

25

43129

BOLT,Hex, M8 x 1.25 x 40mm, LH Thd, Cl 8.8

1шт.

26

43128

BOLT,M8 x 1.25 x 30mm, Cl 8.8

2шт.

27

84334242

GAS STRUT

Bumper

1шт.

28

86629542

NUT,M8 x 1.25, Cl 8.8

2шт.

29

87105622

STEP

2шт.

30

86624183

WASHER,6.6mm ID x 25mm OD x 1.6mm Thk

3шт.

31

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

2шт.

32

43139

BOLT,M10 x 1.5 x 25mm, Cl 8.8

2шт.

33

86511323

WASHER,10.5mm ID x 20mm OD x 2mm Thk

7шт.

34

120070

BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8

2шт.

35

100037

LOCK NUT,M10 x 1.5, Cl 8

2шт.

36

120104

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

25шт.

37

86625199

SELF-TAP SCREW,Hex, M6 x 1 x 13mm

3шт.

38

412649

BELLEVILLE WASHER,M6 Bolt Size x 18mm OD x 1.4mm Thk

1шт.

39

86998687

STUD

2шт.

40

86508813

NUT,M5, Cl 8

2шт.

41

86625201

SELF-TAP SCREW,M8 x 1.25 x 30mm L

2шт.

42

87585661

SHEET METAL

1шт.

43

87284531

NUT,Rivnut, M8 x 1.25, 0.5mm - 3mm Grip Range

4шт.

44

158188

PLUG,19mm Hole, 28.6mm OD

1шт.

45

80401502

ANTI-SKID STRIP

Roll, L = 18.3M; Cut To Fit

1шт.

46

120100

BOLT,M6 x 20mm, Cl 8.8

2шт.

For EU Only

1шт.

47

9706755

NUT,M6, Cl 8

2шт.

For EU Only

1шт.

48

84432904

DECAL

No Step

1шт.

49

84193633

WIRE HARNESS

Service Light; Used Only In Single Plane Upgrade Kit

1шт.

50

84181355

SERVICE KIT

Single Plane Upgrade

1шт.

Выбрано товаров: 52
