Артикул
Название
Примечание
Количество
1
84174156
BEARING ASSY
Bearing, Six-Bolt; Includes: Ref 7
1шт.
2
87282228
SHAFT
1шт.
3
87109088
BEARING ASSY
Support - Includes Refs 7 & 27
1шт.
Please Read Figure Note
1шт.
4
86997578
KEY,10mm W x 94.2mm OAL x 8mm Thk
Retaining
1шт.
5
87629096
PULLEY,218mm OD
1шт.
7
NSS
NOT SOLD SEPARAT
Bearing
2шт.
8
86999341
PULLEY,218mm OD
Driver, Tailings
1шт.
10
86997063
GROOVED BUSHING,50.04mm ID x 94.49mm OD x 20.83mm Thk
1шт.
11
9848973
NUT,M24 x 3.0, Cl 10
2шт.
12
87619879
HUB,44.0125mm ID x 62mm Thk
1шт.
13
Reference Not Used
1шт.
15
87672196
FLANGE BOLT,Hex, M12 x 45mm, Cl 10.9
M12 x 45
6шт.
16
140048
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
8шт.
19
86997496
BUSHING,40.09mm ID x 44.09mm OD x 50mm L
1шт.
20
412479
BOLT,Hex, M8 x 1.25 x 35mm, Cl 8.8
6шт.
21
87011488
HUB,40.02mm ID x 110.8mm Thk
1шт.
24
43235
BOLT,Hex, M8 x 1.25 x 30mm, Cl 10.9, Full Thd
6шт.
25
829-1408
NUT,Hex, M8 x 1.25, Cl 10.9
6шт.
26
825-1408
NUT,M8, Cl 8
6шт.
27
NSS
NOT SOLD SEPARAT
HOUSING, Bearing - Included with Ref 3
1шт.
Выбрано товаров: 27
