Запчасти Case IH 9010 (80.150.05[02]) - GRAIN TANK, L.H. - 9010 (80) - CROP STORAGE/UNLOADING

1

87107644

FRONT SHEET

Frame Window, Black; L/Glass

1шт.

Prior To PIN HAJ200001

1шт.

1

87551223

SHEET ASSY.

Frame, Window, Red; W/Glass

1шт.

PIN HAJ200001 & After

1шт.

1

87551219

SHEET ASSY.

Frame, Window, Red; L/Glass

1шт.

PIN HAJ200001 & After

1шт.

2

86566851

GLASS

1шт.

3

87044294

PANEL

LH, Black

1шт.

Prior To PIN HAJ200001

1шт.

3

87551230

SHEET ASSY.

LH, Red

1шт.

PIN HAJ200001 & After

1шт.

4

87284866

PROFILE

Black

1шт.

Prior To PIN HAJ200001

1шт.

4

87551238

PROFILE

Red

1шт.

PIN HAJ200001 & After

1шт.

5

87284089

PANEL

Black, Includes: Refs 5, 17, 39

1шт.

Prior To PIN HAJ200001

1шт.

5

87510506

PANEL

Black, Side; Component Of 87284089

1шт.

Prior To PIN HAJ200001

1шт.

5

87623431

SERVICE KIT

Panel, Red; Includes: Decals 87551345 & 84432904

1шт.

NA

1шт.

PIN HAJ200001 & After

1шт.

5

87623350

SERVICE KIT

Panel, Red; Includes: Decals 84004740 & 84432904

1шт.

EU

1шт.

PIN HAJ200001 & After

1шт.

6

9992358

ELASTIC STOP

12шт.

7

86584544

DOOR

Black

1шт.

Prior To PIN HAJ200001

1шт.

7

87551376

DOOR

Red

1шт.

PIN HAJ200001 & After

1шт.

8

86975493

BRACKET

Black

1шт.

Prior To PIN HAJ200001

1шт.

8

87551580

BRACKET

Red

1шт.

PIN HAJ200001 & After

1шт.

9

86975460

FLOOR

LH, Black

1шт.

Prior To PIN HAJ200001

1шт.

9

87551366

FLOOR

LH, Red

1шт.

PIN HAJ200001 & After

1шт.

10

87105585

REINFORCEMENT

Black

1шт.

Prior To PIN HAJ200001

1шт.

10

87551407

REINFORCEMENT

Red

1шт.

PIN HAJ200001 & After

1шт.

11

86998708

BRACKET

RH, Black

1шт.

Prior To PIN HAJ200001

1шт.

11

87551415

BRACKET

RH, Red

1шт.

PIN HAJ200001 & After

1шт.

12

86998707

BRACKET

LH, Black

1шт.

Prior To PIN HAJ200001

1шт.

12

87551414

BRACKET

LH, Red

1шт.

PIN HAJ200001 & After

1шт.

13

87106204

CHUTE

1шт.

14

84077354

CLAMP,39mm ID

Black

1шт.

Prior To PIN HAJ200001

1шт.

14

87551606

CLIP

Red

1шт.

PIN HAJ200001 & After

1шт.

15

84077042

BRACKET

1шт.

16

84077041

DOOR

Black

1шт.

Prior To PIN HAJ200001

1шт.

16

87284038

DOOR

Black, Includes: 84077041 & Ref 17

1шт.

Prior To PIN HAJ200001

1шт.

16

87623354

SERVICE KIT

Door, Red; Includes: Decal 84432904

1шт.

PIN HAJ200001 & After

1шт.

17

84432904

DECAL

Do Not Place Foot

2шт.

18

66809

SPRING,Compression, 19.05mm OD x 63.5mm L

1шт.

19

9824840

WASHER,4.3mm ID x 9mm OD x 0.8mm Thk

1шт.

20

362786

FASTENER

1шт.

21

362785

BELLEVILLE WASHER,5.5mm ID x 15mm OD x 0.5mm Thk

1шт.

22

446453

RIVET,Pop, 4mm OD x 9.4mm L

1шт.

23

9706690

NUT,M8 x 1.25, Cl 8

1шт.

24

100016

NUT,M10 x 1.5, Cl 8

1шт.

25

9706685

NUT,M12 x 1.75, Cl 8

1шт.

26

86507486

CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8

8шт.

27

120104

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

1шт.

28

120044

CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8

2шт.

29

86508568

BOLT,Hex, M6 x 1 x 16mm, Cl 8.8

2шт.

30

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

2шт.

31

43138

BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8

1шт.

32

300388

BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8

7шт.

33

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

1шт.

34

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

1шт.

35

140046

BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk

1шт.

36

322357

BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk

2шт.

37

86590413

BASE,15.87mm W x 22.22mm OAL x 9.9mm Thk

Base, Wire Tie

1шт.

38

445394

RIVET,Pop, 3/16" x 1/2" OAL

1шт.

39

84004740

DECAL

1шт.
