Запчасти Case IH 9010 (74.140.06[02]) - ANGLE DRIVE - 9010 (74) - CLEANING

1

87342462

PLATE

1шт.

1

87737490

TOP COVER

Plate

1шт.

Extended Wear

1шт.

2

100016

NUT,M10 x 1.5, Cl 8

4шт.

3

87107888

GEARBOX

1шт.

4

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

8шт.

5

9706704

BOLT,Hex, M10 x 1.5 x 41.58mm, Cl 8.8

4шт.
