Запчасти Case IH 9010 (41.203.03 ) - PTO 1, COMMON HYDRAULIC - 9010 (41) - STEERING

1

87646990

HYDRAULIC PUMP

1шт.

84273626C

CORE-HYDRAULIC PUMP

Return Number, HYDRAULIC PUMP - for N.A. Only

1шт.

87646990C

CORE-HYDRAULIC PUMP

Return Number, HYDRAULIC PUMP - for N.A. Only

1шт.

2

87310111

MOTOR, HYDRAULIC,45.6CC

1шт.

3

9993141

O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro

5шт.

4

86579683

HYD CONNECTOR,1-3/16"-12 ORFS x M33 x 2.0 ORB

1шт.

5

86591334

TEE,11/16"-16 ORFS x 11/16"-16 Fem

Includes: Ref 3 (2)

2шт.

6

86514261

TEE,13/16" - 16 JIC x 13/16" - 16 ORFS x 13/16" - 16 ORFS

1шт.

7

86705424

TEE,1 11/16"-12 ORFS x 1 11/16"-12 Fem Sw Br

1шт.

8

0C

ORDER COMPONENTS

Manifold, Control Pressure

1шт.

9

0C

ORDER COMPONENTS

Manifold, Return

1шт.

10

87624691

HYD TUBE,0.375" OD

Reg To Feeder Clutch From Manifold

1шт.

11

87624693

HYD TUBE,0.625" OD

Charge To Propulsion Pump

1шт.

12

87624692

HYD TUBE,0.5" OD

Charge To Rotor Pump

1шт.

13

87601525

HYD TUBE,1.25" OD

Lube & Charge Pump Connector

1шт.

14

87563479

HYD TUBE,1.25" OD

PTO Oil Pan Suction to Tee

1шт.

Replaces One-Piece Production Tube

1шт.

15

87587903

HYD TUBE,1.25" OD

Return From Drain Manifold

1шт.

16

87587902

HYD TUBE,1" OD

Ground Drive Pump Drain

1шт.

17

87284931

HYD TUBE,0.75" OD

Lube To Filter

1шт.

18

86995885

HYD TUBE,0.50" OD

Feeder Clutch Lube Supply

1шт.

19

86995872

HYD TUBE,0.375" OD

Rotor Clutch Regulated Supply

1шт.

20

87314312

FLEXIBLE HOSE

Rotor Drive B

1шт.

21

87314311

FLEXIBLE HOSE,19mm ID x 1200mm L

Rotor Drive A

1шт.

22

87587907

HYD TUBE,0.5" OD

Return Manifold to Rotor Drive Motor

1шт.

23

86980732

CLAMP

4шт.

24

86625255

WASHER,13.3mm ID x 24.5mm OD x 3mm Thk

8шт.

25

87022684

BOLT,Hex, M12 x 45mm, Cl 10.9

12шт.

26

9828498

O-RING,0.103" Thk x 3.987" ID, -155, Cl 5, 75 Duro

2шт.

27

274336

O-RING,0.103" Thk x 4.737" ID, -158, Cl 5, 75 Duro

1шт.

28

86625256

WASHER,13.3mm ID x 28.5mm OD x 4mm Thk

8шт.

29

87022683

BOLT,Hex, M12 x 40mm, Cl 10.9

4шт.

30

86995994

HYD TUBE,0.375" OD

Rotor Clutch Pressure

1шт.

31

86995887

HYD TUBE,0.375" OD

Clutch Pressure Supply To UNL

1шт.

32

86579671

HYD CONNECTOR,11/16" - 16 ORFS x M14 x 1.5 ORB

1шт.

33

86529541

O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro

2шт.

34

86598099

O-RING,2.2mm Thk x 11.3mm ID, Cl 6

1шт.

35

87324916

BRACKET

Lower, Rotor Drain

1шт.

36

87324918

BRACKET

Upper, Rotor Drain

1шт.

37

378245

WASHER,13mm ID x 28.5mm OD x 2.7mm Thk

2шт.

38

433008

CLAMP

4шт.

39

442340

SUPPORT

2шт.

40

120056

BOLT,M6 x 1.0 x 54.15mm, Cl 8.8

2шт.

41

353308

NUT,M6 x 1.0, Cl 8

2шт.

42

140046

BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk

1шт.

43

9706687

BOLT,M12 x 1.75 x 30mm, Cl 8.8

1шт.

44

86503302

O-RING,0.139" Thk x 0.984" ID, -214, Cl 6, 90 Duro

2шт.

45

86980731

CLAMP

4шт.

46

86639325

WASHER,10.8mm ID x 24.5mm OD x 3mm Thk

8шт.

47

87315279

BOLT,Hex, M10 x 35mm, Cl 10.9

8шт.

48

86579708

TEE,1-11/16" - 12 ORFS x 1-11/16" - 12 ORFS x M42 x 2 ORB

1шт.

49

86579685

HYD CONNECTOR,1 11/16"-12 ORFS x M42 x 2 ORB

1шт.

50

86579682

HYD CONNECTOR,1-3/16" - 12 ORFS x M27 x 2 ORB

2шт.

51

86598104

O-RING,2.9mm Thk x 29.6mm ID, Cl 6, 90 Duro

3шт.

52

294721A1

HYDRAULIC OIL FILTER

Element

1шт.

53

87563478

HYD TUBE,1.25" OD

PTO Oil Pan Suction to Tee

1шт.

Replaces One-Piece Production Tube

1шт.

54

86598103

O-RING,2.9mm Thk x 23.6mm ID, Cl 6, 90 Duro

3шт.

55

9991976

O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro

3шт.

56

9824050

O-RING,0.07" Thk x 0.926" ID, -21, Cl 6, 90 Duro

2шт.

57

86579697

ELBOW,90 Degree, 1-3/16"-12 ORFS x M27 x 2.0 ORB

Includes: Refs 54 & 55

2шт.

58

86598105

O-RING,2.9mm Thk x 38.6mm ID, Cl 6, 90 Duro

2шт.

59

9824051

O-RING,0.07" Thk x 1.176" ID, -25, Cl 6, 90 Duro

4шт.

60

87662557

SENSOR

1шт.

61

86639056

ELBOW,45 Degree, 13/16"-18 ORFS x M18 x 1.5 ORB

1шт.

62

86998689

HYDRAULIC OIL FILTER

Includes: Ref 52

1шт.

63

86580179

HYD CONNECTOR,1-7/16" - 12 ORFS x M33 x 2 ORB

Includes: Refs 51 & 56

3шт.

64

43138

BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8

4шт.

65

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

4шт.
