Запчасти Case IH AF4077 (50.104.AQ) - AIR FILTER, CAB (50) - CAB CLIMATE CONTROL

1

47712476

Grain Tank Front, RH, Use for 2015

SHEET

1шт.

1

47856878

Grain Tank Front, RH, Use from 2016

SHEET

1шт.

2

47531201

Assy, Cab Air Filter, Incl 3

MOUNT

1шт.

3

NSS

NOT SOLD SEPARAT

Cab Air Filter, Incl in 2

1шт.

4

84057675

CLAMP BRACKET

1шт.

5

47537878

Weld Assy, Air, Use for 2016

DUCT

1шт.

5

47948264

Weld Assy, Air, Use from 2017

DUCT

1шт.

6

47730725

Weld Assy, Cab Air Filter

COVER

1шт.

7

47581023

Cab Air Filter

COVER

1шт.

8

47581027

Weld Assy, Cab Air Filter

COVER

1шт.

9

47531190

Hook Anchor, RH

BRACKET

1шт.

10

47531194

Bracket, Hook Anchor, LH

SUPPORT

1шт.

11

86050300

FLANGE NUT,M6 x 1.0, Cl 10

Use for 2016

6шт.

11

86050300

FLANGE NUT,M6 x 1.0, Cl 10

Use from 2017

7шт.

12

87675531

FLANGE BOLT,M6 x 26.6mm, Cl 10.9

11шт.

13

86507066

FLANGE NUT,M8 x 1.25, Cl 10

15шт.

14

87656137

BOLT,Flange Hex, M8 x 20mm, Cl 10.9

15шт.

15

445394

RIVET,Pop, 3/16" x 1/2" OAL

14шт.

16

47707784

Assy, RH, Feeder Drive Shield, Incl 17 - 18

MOUNT

1шт.

17

NSS

NOT SOLD SEPARAT

Mount, RH, Feeder Drive Shield, Incl in 16

1шт.

18

NSS

NOT SOLD SEPARAT

Nut, Incl in 16

2шт.

19

87000778

PLUG,89mm OD

1шт.

20

47763035

NUT

4шт.

21

87686906

LATCH

Handle, Door, Use for 2016

1шт.

21

47464322

Door, Use from 2017

HANDLE

1шт.

22

140041

WASHER,M8 x 28mm OD x 3mm Thk

2шт.

23

87698833

BOLT,M8 x 33.1mm, Cl 10.9

2шт.

24

84334657

AIR CLEANER

Assy, Incl 25, 26

1шт.

25

47132327

COVER

Assy Neutral

1шт.

26

87682993

AIR FILTER,91mm ID x 164.5mm OD x 347.5mm L

Engine, Primary

1шт.

27

87651811

GASKET

Air Filter

1шт.

28

9809800

DUST VALVE,1.93" ID x 2.24" OD

Vacuator

1шт.

29

84591621

TUBE

Duct, Cab Pressure

1шт.

30

47591654

Assy, Cab Pressure

HOSE

1шт.

31

87040758

HOSE CLAMP,71.4mm - 95.2mm

2шт.

32

381144

HOSE CLAMP,84.1mm - 107.9mm, Worm Gear

1шт.

33

47732197

Cab Air Filter

SUPPORT

2шт.

34

86511826

SCREW,Phillips Drive, Pan HD, M5 x 16mm

Trim Hook, Use from 2017

4шт.

35

847-3616

SERRATED SCREW,Sl Truss, M6 x 16mm, Cl 10.9

Use for 2016

4шт.

35

764071C2

BRACKET

Trim Hook, Use from 2017

2шт.

36

86512495

FLANGE NUT,Hex, M5, Cl 8

4шт.

37

47948261

Cab Weld Assy, Use from 2017

AIR FILTER

1шт.

38

87062C1

GASKET

Trim, Edge, Use from 2017

1шт.

39

48107194

Kit, Installation Cab Air Inlet, Incl 40 - 43, Use From 2017

INSTRUCTION

1шт.

40

86588108

Wrapper, Shrink, Use From 2017

KIT

1шт.

41

86589460

BAG

Dessicant-One Unit, Use From 2017

1шт.

42

48107197

Cab Air Inlet Kit, Use From 2017

INSTRUCTION

1шт.

43

86588125

INSTRUCTION

Plate, Identity, Use From 2017

1шт.
