Запчасти Case IH 9240 (10.419.AA[04]) - SCREEN, AIR INTAKE (10) - ENGINE

1

87681207

BOLT,M8 x 24.1mm, Cl 10.9

14шт.

2

84598565

SCREEN

Wedge Perforated, Air

6шт.

3

47581485

BRACKET

Knife, SAS Door

3шт.

4

84598567

STRIP

SAS Door, Support

3шт.

5

87644487

RIVET,Pop, 4.76mm OD x 10.92mm L

76шт.

6

84598573

RING

Outer Retaining

6шт.

7

47700272

FLANGE

52mm Bearing Housing

2шт.

8

325103

BALL BEARING,25mm ID x 52mm OD x 15mm W

1шт.

9

87284531

NUT,Rivnut, M8 x 1.25, 0.5mm - 3mm Grip Range

2шт.

10

86507066

FLANGE NUT,M8 x 1.25, Cl 10

3шт.

11

47692743

NOZZLE

Air Screen, Assy

1шт.

12

86639313

WASHER,9mm ID x 24mm OD x 2mm Thk

2шт.

13

87682384

CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 10.9

2шт.

14

87663397

SPACER,19mm W, 100mm Centerline Length

1шт.

15

14642191

RIVET,Pop, 3.9mm OD x 14mm OAL

24шт.

16

10619520

KEY,8mm W x 20mm L x 7mm H

1шт.

17

87607602

PULLEY ASSY.

Belt Idler, Tensioiner

1шт.

18

87682772

PULLEY,25.05mm ID x 100mm OD x 79mm W

1шт.

19

87698836

BOLT,M10 x 25mm, Full Thd, Cl 10.9

4шт.

20

87698834

BOLT,M8 x 48.1mm, Cl 10.9

1шт.

21

12642804

WASHER,4.15mm ID x 12mm OD x 1mm Thk

40шт.

22

47529522

DUCT

Outer, Assy

1шт.

23

47591561

BRACKET

Baffle

1шт.

24

47591566

COVER

Screen Door

1шт.

25

47705762

SUPPORT

Bracket, Outer Duct Assy

1шт.

26

47388130

SEAL

277.1mm L x 180mm Thk, Rubber

1шт.

27

47390376

SEAL

619mm L x 180mm Thk, Rubber

1шт.

28

47390377

SEAL

795mm L x 180mm Thk, Rubber

1шт.

29

47602500

SEAL

276mm L x 180mm Thk, Rubber

1шт.

30

47395508

ANGLE

740mm L x 59.6mm Thk, Mounting Plate

1шт.

31

87030775

BOLT,M8 x 38.1mm, Cl 10.9

1шт.

32

378243

WASHER,8.4mm ID x 21mm OD x 1.6mm Thk

2шт.

33

86623991

CABLE,2 Eyelet, 490mm Centerline Length

1шт.

34

87681210

FLANGE NUT,M8 x 1.25, Cl 10

1шт.

35

87107072

CHAIN LINK,44.299mm Pitch

1шт.

36

47735883

HUB

Rotating

1шт.

37

47361833

PLATE

Nozzle Brace

1шт.

38

87472745

RING,140mm ID x 205mm OD x 24mm Thk

1шт.

39

87724601

SELF-TAP SCREW,M6 x 1.0 x 17mm, Cl 10.9

4шт.

40

9824326

WASHER,5.3mm ID x 10mm OD x 1mm Thk

14шт.

41

445395

RIVET,Pop, 4.8mm OD x 18.1mm L

14шт.

42

47514305

RING,165mm ID x 205mm OD x 12mm Thk

1шт.

43

47662307

CLIP

Retaining, SAS Hub

1шт.
