Артикул
Название
Примечание
Количество
1
87601391
ROTOR ASSY.
Small Tube, 40 Element, Rice, ABR, Incl 15 - 31
1шт.
3
87603593
COVER ASSY
Rotor Gearbox
1шт.
4
87323577
RING
Reluctor Wheel, Rotor Speed
1шт.
5
87284474
SHIM,51.18mm ID x 59.7mm OD x 1mm Thk
59.7mm OD x 51.18mm ID
1шт.
6
87281633
SPACER,50.88mm ID x 66.68mm OD x 44mm L
1шт.
7
87107260
SUPPORT
Bracket, Lube Line
1шт.
8
87107259
HOSE,3.02mm ID x 737mm L
1шт.
10
86981489
BOLT,Hex, M16 x 70mm, Cl 10.9
1шт.
11
43127
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
4шт.
12
134814
NUT,11/16"
11/16" Thread
1шт.
13
9706690
NUT,M8 x 1.25, Cl 8
4шт.
14
86998693
WASHER,17.8mm ID x 76.2mm OD x 9.5mm Thk
1шт.
15
87378268
AUGER FLIGHT
Inlet
2шт.
16
87315598
SHIELD
Bolt Protection
4шт.
17
47603368
RASP BAR
Spiked
40шт.
18
87396383
PLATE ASSY.
Helical Kicker Wear
2шт.
19
86625255
WASHER,13.3mm ID x 24.5mm OD x 3mm Thk
2шт.
20
87342923
WEAR PLATE
Rotor Flighting
2шт.
21
87697368
PLASTIC PLUG
Rotor Tube, Rear
1шт.
22
86981487
BOLT,Flange, M12 x 35mm, Full, Cl 10.9 DOR
42шт.
23
9843611
BOLT,Hex, M16 x 2.0 x 55mm, Cl 10.9
2шт.
24
87394282
PLOW BOLT,M16 x 55mm, Cl 10.9
M16 x 55mm OAL
12шт.
25
87314103
PLOW BOLT,M12 x 1.75 x 40mm, Cl 10.9
M12 x 40mm OAL, Cl 10.9
10шт.
26
86512380
FLANGE NUT,M16
22шт.
27
412672
NUT,Hex, M12 x 1.75, Cl 10
12шт.
28
NSS
NOT SOLD SEPARAT
Rotor, Incl in 1
1шт.
29
84222993
SPLINED COUPLING,12T
Rotor Drive
1шт.
31
86577946
BOLT,Hex, M16 x 80mm x 10.9
8шт.
Выбрано товаров: 31
