Артикул
Название
Примечание
Количество
1
84335089
SUPPORT ASSY.
1шт.
2
140046
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
18шт.
5
87676814
TANK
1000 L
1шт.
6
87676819
FUEL FILTER
Tank
1шт.
7
87743275
FUEL HOSE,10mm ID x 2593mm L, SAE 100R6
Fuel Return
1шт.
8
87676817
SENDER UNIT
1шт.
9
86511826
SCREW,Phillips Drive, Pan HD, M5 x 16mm
6шт.
10
86999947
GROMMET,25mm ID x 33mm OD, 46mm Shoulder
1шт.
11
86999948
SAFETY VALVE
1шт.
12
87734872
FUEL HOSE,6.35 mm ID x 630.00 mm, SAE 30R6 Or SAE 30R7
Hose Fuel Vent
1шт.
14
86999949
FUEL FILTER
Filter Air Vent
1шт.
15
86010402
CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, P Type
1шт.
17
120069
BOLT,M10 x 1.5 x 56.58mm OAL, Cl 8.8
1шт.
18
100016
NUT,M10 x 1.5, Cl 8
13шт.
19
87728317
ELBOW
1шт.
20
144599
1шт.
23
87734863
PLATE ASSY.
1шт.
24
NS
NOT SERVICED
Fuel Filter, See Page 10.216.01(02)
1шт.
25
87676818
FUEL PUMP,12V, 4.5A
1шт.
26
87734804
BRACKET
1шт.
27
84132594
SPACER,10.7mm ID x 17.1mm OD x 30mm OAL
1шт.
28
87734807
BRACKET
1шт.
29
87482602
BRACKET
1шт.
30
43127
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
2шт.
31
87035448
SPACER,8.48mm ID x 12.7mm OD x 12.7mm L
2шт.
32
9706748
CLAMP,15.9mm, Coat, 8.7mm Bolt Hole, P Type
2шт.
33
578070
CLAMP,19mm, Coat, 8.7mm Bolt Hole, P Type
2шт.
35
9706690
NUT,M8 x 1.25, Cl 8
4шт.
38
201-326
ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x 7/8" - 14 Male ORB
1шт.
39
87728316
FUEL TUBE,.5" OD
1шт.
40
201-327
ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x 1-1/16" - 12 Male ORB
1шт.
41
87728315
HOSE
1шт.
42
87743277
CONDUIT
1шт.
43
120103
BOLT,M8 x 1.25 x 16mm, Cl 8.8
1шт.
44
86566989
CABLE TIE,208mm L
1шт.
45
87743281
FUEL HOSE,10mm ID x 2960mm L, SAE 100R6
Fuel Supply
1шт.
46
87029955
CLAMP,22.2mm, Coat, 10.3mm Bolt Hole, P Type
1шт.
47
87105416
HOSE PROTECTION,16.64 mm ID x 1345.00 mm
2шт.
48
43140
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
14шт.
49
87750278
CHANNEL
1шт.
51
86512512
PLUG,7/8" - 14 ORB
2шт.
52
87679098
DECAL,37mm x 70mm
1шт.
53
87283963
INSULATOR
1шт.
54
87029955
CLAMP,22.2mm, Coat, 10.3mm Bolt Hole, P Type
1шт.
55
400981
SEALANT
1шт.
56
84132594
SPACER,10.7mm ID x 17.1mm OD x 30mm OAL
1шт.
57
87679098
DECAL,37mm x 70mm
1шт.
58
NSS
NOT SOLD SEPARAT
Not Used in Application
1шт.
59
84354931
FITTING
1шт.
Выбрано товаров: 59
