Запчасти Case IH 9230 (74.130.01[01]) - CLEANING FAN (74) - CLEANING

1

87589411

SHAFT

Cleaning Fan

1шт.

1

87495205

SHAFT ASSY.

Cleaning Fan, NA And EU, Used Only With 710 or 900 Narrow Tire Option, 82/9230 Only

1шт.

2

86980769

DISC

Cleaning Fan

5шт.

3

331175

BOLT,Hex, M8 x 1.25 x 75mm, Cl 8.8

Cap, HH, CL 8.8, M8 x 1.25 s 75

5шт.

4

86625263

WASHER,9mm ID x 20mm OD x 1.6mm Thk

10шт.

5

86629542

NUT,M8 x 1.25, Cl 8.8

5шт.

6

86997034

FAN BLADE

Cleaning Fan

40шт.

7

393599

SET SCREW,M10 x 25mm, Cl 12.9

2шт.

8

100016

NUT,M10 x 1.5, Cl 8

6шт.

9

87635286

COVER ASSY

Wrapper, Cleaning Fan

1шт.

10

87318136

HOUSING

1шт.

11

9804258

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

11шт.

12

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

17шт.

14

86997109

PLATE

Fan Bearing Support

2шт.

15

86512446

CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8

4шт.

16

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

4шт.

17

80328430

BOLT

Carriage, CL 8.8, M12 x 1.75 x 35

8шт.

18

140046

BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk

8шт.

19

9804279

FLANGE NUT,Hex, M12, Cl 8

8шт.

20

86979948

FLANGE

4шт.

21

668719R92

BEARING ASSY,1.7505" ID x 3.346" OD x 1.1875" Thk

2шт.

22

45631

COLLAR

Locking

1шт.

23

86999734

COLLAR,44.48mm ID x 63.5mm OD x 18.3mm W

Cleaning Fan, Speed Pick-up

1шт.

24

86999732

BRACKET

Cleaning Fan Speed Sensor

1шт.

25

84058861

SENSOR

Cleaning Fan Speed, Two-Wire, M12 Thread

1шт.

25

87342073

SENSOR

Cleaning Fan Speed, M18 Thread

1шт.

26

87487017

FAN

Assembly: Incl Refs 1 (87495205) Thru 7

1шт.

26

87107366

FAN

Assembly; Incl Refs 1(87589411) Thru 7

1шт.

27

87635283

ROD

2шт.

28

86624176

WASHER,11mm ID x 20mm OD x 2mm Thk

6шт.

29

130003

COTTER PIN,3mm OD x 30mm OAL

4шт.

30

647695

PIN,7.94mm OD

1шт.

31

87663339

HANDLE

1шт.

33

43140

BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8

2шт.

34

80702

WASHER,0.44" ID x 1" OD x 0.08" Thk

4шт.

35

626698

SPACER

2шт.

36

100037

LOCK NUT,M10 x 1.5, Cl 8

2шт.

37

87477999

BRACKET

L.H.

1шт.

38

87478001

BRACKET

R.H.

1шт.

39

87478003

DOOR

1шт.

40

87663341

LATCH

1шт.

41

87399163

SPROCKET

Speed Pickup

1шт.
