Запчасти Case IH 9230 (44.100.10) - WHEEL, FRONT,900/75R32, NA AND ANZ ONLY (44) - WHEELS

1

NS

NOT SERVICED

Procure Locally

1шт.

2

84200754

RIM

WHEEL ASSY, 32XDW30B SILVER

1шт.

3

87106339

VALVE STEM

1шт.

4

87106340

PLUG

1шт.

5

NS

NOT SERVICED

Tube (Not Shown)

1шт.

6

87570139

DECAL

Bolt Torquing Sequence

1шт.
