Запчасти Case IH 9230 (44.100.02) - WHEEL, FRONT-900/60R32 (44) - WHEELS

1

NS

NOT SERVICED

Procure Tire Locally

1шт.

2

84200754

RIM

WHEEL ASSY, 32XDW30B SILVER, NA And ANZ Only

1шт.

2

87682368

RIM

WHEEL ASSY, 32XDW30B SILVER, EU Only

1шт.

3

87106339

VALVE STEM

1шт.

4

87106340

PLUG

For Tubeless Tire

1шт.

5

NS

NOT SERVICED

Tube, Procure Locally (Not Shown)

1шт.

6

87570139

DECAL

Bolt Torquing Sequence

1шт.
