Запчасти Case IH 9120 (80.101.18) - GRAIN ELEVATOR TENSIONER & CHAIN (80) - CROP STORAGE/UNLOADING

1

87470737

CHAIN,RC60, 104 Links x 19.05mm = 1981.08mm

Roller, 104 Links, 1981.08 MM, Long

1шт.

2

87282471

BLADE

35шт.

3

87470738

LINK,19.05mm Pitch

Connector; Incl Shepherd's Hook Fastener

1шт.

4

87281911

ELEVATOR CHAIN,CA550HD, 145 Links x 41.4mm = 6003mm

1шт.

5

86998942

PIN

1шт.

5

84214452

GROOVED PIN

MY10, must be used for new Grain Tank Cover

1шт.

6

87284481

SUPPORT

1шт.

7

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

20шт.

8

120104

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

7шт.

9

9706690

NUT,M8 x 1.25, Cl 8

13шт.

10

140048

BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk

2шт.

11

825-1416

NUT,M16, Cl 8

2шт.

12

359211

BOLT,M16 x 2.0 x 150mm, Cl 8.8

1шт.

13

216698

COTTER PIN,0.125" OD x 1.75" L

2шт.

14

87282356

CONNECTING LINK

Incl S-Pin

1шт.

14

87610182

PIN,3.17mm OD

S

1шт.

15

86999835

RIVET

1шт.

16

86575773

LINK CHAIN

Roller

1шт.

17

86995345

LINK,Chain

6шт.

18

87281918

LINK,550 HD, 3 Links x 41.4mm = 124.2mm

Blade Attachment

1шт.

19

87281909

LINK CHAIN

Attachment

1шт.

20

23442R1

PIN,2.36mm OD

S - For Ref 17 - NOT SHOWN

1шт.

21

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

6шт.

22

87678426

PIVOT ASSY.

2шт.

23

43140

BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8

2шт.

24

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

2шт.

25

140042

WASHER,11mm ID x 34mm OD x 3mm Thk

2шт.
