Артикул
Название
Примечание
Количество
1
84100965
SIEVE
HC Slat, 1 1/8" (7 to 24) - PAINTED
2шт.
Part is Not Remote Ready; Refer to Ref 27
1шт.
1
87109830
SIEVE
CLOSZ Slat, 1 1/8"(7 to 24) - GALVANIZED
2шт.
Part is Not Remote Ready; Refer to Ref 27
1шт.
1
84320037
SIEVE
Closz Slat, 1 5/8" (7 to 17, 22 to 24) - PAINTED
2шт.
Part is Not Remote Ready; Refer to Ref 27
1шт.
1
87109834
SIEVE
Corn, 1 5/8"(7 to 24) - GALVANIZED
2шт.
Part is Not Remote Ready; Refer to Ref 27
1шт.
1
87109838
SIEVE
CLOSZ Slat, 1 5/8"(7 to 24) - GALVANIZED
2шт.
Part is Not Remote Ready; Refer to Ref 27
1шт.
1
84100990
SIEVE
Peterson, 1 1/8"(7 to 24) - PAINTED
2шт.
Part is Not Remote Ready; Refer to Ref 27
1шт.
1
87109842
SIEVE
Peterson, 1 1/8"(7 to 24) - GALVANIZED
2шт.
Part is Not Remote Ready; Refer to Ref 27
1шт.
1
84437315
SIEVE
CLOSZ Slat, 1 1/8" (7 to 24) - PAINTED
2шт.
Part is Not Remote Ready; Refer to Ref 27
1шт.
2
86508568
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
1шт.
4
84320875
SEAL,300mm W x 764mm OAL
1шт.
5
84100961
RAKE,151mm L
2шт.
6
9706755
NUT,M6, Cl 8
1шт.
7
84056237
ADJUSTING PLATE
1шт.
For 1-1/8" Sieve Only
1шт.
7
84056235
ADJUSTING PLATE
1шт.
For 1-5/8" Sieve Only
1шт.
8
84056254
INDICATOR
1шт.
For 1-1/8" Sieve Only
1шт.
8
84056253
INDICATOR
1шт.
For 1-5/8" Sieve Only
1шт.
9
378243
WASHER,8.4mm ID x 21mm OD x 1.6mm Thk
2шт.
10
426565
QUADRANT
2шт.
11
84053320
LEVER
1шт.
For 1-1/8" Sieve Only
1шт.
11
84056678
PLATE
1шт.
For 1-5/8" Sieve Only
1шт.
12
86508568
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
2шт.
13
9817781
HANDLE
2шт.
14
432187
HANDLE
2шт.
15
353308
NUT,M6 x 1.0, Cl 8
2шт.
17
449942
SPRING
2шт.
18
84056802
INDICATOR
1шт.
For 1-1/8" Sieve Only
1шт.
19
84056247
ROD
1шт.
For 1-1/8" Sieve Only
1шт.
20
84053321
LEVER
1шт.
For 1-1/8" Sieve Only
1шт.
21
84056236
ADJUSTING PLATE
1шт.
For 1-1/8" Sieve Only
1шт.
23
453189
WIRE
1шт.
For 1-1/8" Sieve Only
1шт.
24
324715
BAR,HC 1-1/8" x 230mm overall length
HC 1 1/8"-230
94шт.
24
80445568
BAR,HC 1-5/8" X 240mm overall length
HC 1 5/8"-240
33шт.
24
80396505
BAR,HC 1-5/8" X 230mm overall length
HC 1 5/8"-230
66шт.
24
80445568
BAR,HC 1-5/8" X 240mm overall length
HC 1 5/8"-240
165шт.
25
89832566
BAR,Peterson 240mm overall length
HC 1 1/8"-240
47шт.
25
89832565
BAR,Peterson 230mm overall length
HC 1 1/8"-230
94шт.
25
89832566
BAR,Peterson 240mm overall length
HC 1 1/8"-240
235шт.
26
84100993
PLATE
2шт.
27
84084984
SIEVE,Kit, UPPER HC 1-1/8"
Kit, HC, 1-1/8"; Incl Ref 1, 87109830 (2), Ref 2, 86508568 (8), Ref 3, 412653 (16), Ref 5, 84100961 (2), Ref 6, 9706755 (8)
1шт.
27
84084981
DIA KIT, HARVESTER
Kit, PET, 1-1/8"; Incl Ref 1, 87109842 (2), Ref 2, 86508568 (8), Ref. 3, 412653 (16), Ref 5, 84100961 (2), Ref 6, 9706755 (8)
1шт.
27
84084324
DIA KIT, HARVESTER
Closz, 1-5/8"; Incl Ref 1, 87109838 (2), Ref 2, 86508568 (8), Ref. 3 412653 (16), Ref 5, 84100961 (2), Ref 6, 9706755 (8)
1шт.
28
453266
SIEVE EXTENSION
Optional Graepel Sieve Extension - 784 mm Long. For 8120
2шт.
28
430384
PLATE
. For 8120
1шт.
29
84084664
DIA KIT, HARVESTER
Chaffer, Adj, 1-5/8"; Incl Ref 1, 87109834 (2), Ref 2, 120100 (8), Ref 3 (16), Ref 4 (2), Ref 5, 84100961 (2), Ref 6 (8), Plus Remote Plates & Hdw. For 8120
1шт.
Выбрано товаров: 69
