Запчасти Case IH 8120 (44.101.02) - DIA, HARVEST KIT, AXLE EXTENSION, EUROPEAN ONLY (44) - WHEELS

1

84258086

SHAFT

Traction 22T-2M x 631

1шт.

2

84258089

SHAFT

Traction 22T-2M x 891

1шт.

3

84258091

CONNECTING ROD

European Axle Extension

1шт.

4

87108364

EXTENSION

L.H. Extension

1шт.

5

87108362

EXTENSION

R.H. Extension

1шт.

6

626826

DOWEL,29.92mm OD x 35.1mm L

4шт.

7

87024335

BOLT,Hex, M20 x 80mm, Cl 10.9

16шт.

8

394632

WASHER,21mm ID x 40mm OD x 4mm Thk

32шт.

9

87024336

NUT,M20 x 2.5, Cl 10

16шт.

10

80140184

WASHER,31mm ID x 50mm OD x 3mm Thk

2шт.

11

300852

NUT,M30 x 1.5, Cl 8

2шт.

12

87325518

INSTRUCTION

1шт.
