Запчасти Case IH 8010 (60.110.08[01]) - FEEDER FRAME - PRIOR TO PIN HAJ202001 - 7010/8010 (60) - PRODUCT FEEDING

1

86995292

HOUSING

Includes: Decals & Anti-Skid Pads

1шт.

1

87283143

HOUSING ASSY.

1шт.

For EU Only

1шт.

2

87106719

BRACKET

2шт.

3

87109542

GEARBOX

1шт.

87610913R

REMAN-GEARBOX

7010, 8010 Both Prior To P.I.N. HAJ200001, Reman For New P/N's 87109542 & 87610913,

1шт.

87610913C

CORE-GEARBOX

Return Number

1шт.

4

87282452

PLATE

2шт.

5

87281691

BOLT,Special Bolt, M16 x 2 x 68.9mm OAL 10mm W Flat

2шт.

6

87281673

PIN,44mm OD x 127mm L

Weld ASSY

2шт.

7

362810

WASHER,11mm ID x 30mm OD x 5mm Thk

1шт.

8

87109127

BOLT

Eye

2шт.

9

9804277

FLANGE NUT,Hex, M8 x 1.25, Cl 8

1шт.

10

87282445

PIN,41.27mm OD x 218mm L

4шт.

11

80752

COTTER PIN,1/4" x 2 1/2"

8шт.

12

87108395

U-BOLT,M8 x 1.25, 145mm OAL x 95mm W

1шт.

13

86974037

FLANGE

2шт.

14

86575514

BALL BEARING,34.92mm ID x 80mm OD x 24.3mm W

1шт.

15

45393

COLLAR

1шт.

17

87108951

SHIELD

L.H.

1шт.

18

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

1шт.

19

43139

BOLT,M10 x 1.5 x 25mm, Cl 8.8

1шт.

20

100016

NUT,M10 x 1.5, Cl 8

34шт.

21

43140

BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8

4шт.

22

140046

BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk

6шт.

23

140048

BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk

12шт.

24

120091

SCREW,Hex, M16 x 60mm, Cl 8.8

8шт.

25

825-1416

NUT,M16, Cl 8

4шт.

26

87021758

NUT,M12 x 1.75, Cl 10

5шт.

27

86638316

LATCH

2шт.

28

86999166

SHAFT

Conveyor Jackshaft

1шт.

29

87108942

SHIELD

R.H.

1шт.

30

120104

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

8шт.

31

9706690

NUT,M8 x 1.25, Cl 8

8шт.

32

87326647

WIRE HARNESS

W/ Reel Position Sensors

1шт.

33

120103

BOLT,M8 x 1.25 x 16mm, Cl 8.8

1шт.

34

9804263

BOLT,M10 x 49.2mm, Cl 8.8

2шт.

35

87301326

BOLT,M12 x 1.75 x 82.68mm, Cl 10.9

1шт.

36

87283910

GUARD

1шт.

37

86592703

WASHER,21mm ID x 50mm OD x 6mm Thk

14шт.

38

86512499

FLANGE NUT,M20 x 2.5, Cl 10

14шт.

39

86981478

CARRIAGE BOLT,M20 x 70.9mm, Cl 10.9

14шт.

40

86629541

BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8

4шт.

43

86512498

FLANGE NUT,M16 x 2, Cl 10

1шт.

44

86050286

FLANGE BOLT,M10 x 20mm, Cl 8.8

6шт.

46

86512446

CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8

4шт.

47

87021759

BOLT,M12 x 1.75 x 60mm, Cl 10.9

4шт.

48

86590413

BASE,15.87mm W x 22.22mm OAL x 9.9mm Thk

Base, Wire Tie

4шт.

49

445395

RIVET,Pop, 4.8mm OD x 18.1mm L

4шт.

50

87282755

DEFLECTOR

L.H., Aluminum

1шт.

52

86999167

SHAFT

Feeder Jack

1шт.

53

87282756

DEFLECTOR

R.H., Aluminum

1шт.

54

120075

BOLT,M10 x 1.5 x 106.58mm, Cl 8.8

2шт.

55

412151

BOLT,M10 x 1.5 x 61.58mm, Cl 8.8

2шт.

56

83931335

BOLT,Hex, M10 x 1.5 x 75mm, Cl 8.8

2шт.

57

87564959

CHANNEL

1шт.

58

87283141

RETAINING WIRE

1шт.

59

87108949

SHIELD

R.H.

1шт.

60

87108945

SHIELD

L.H., Includes Decal

1шт.

61

84004742

DECAL

1шт.

62

87107921

GROMMET,19mm ID x 41mm OD x 30mm Thk

1шт.

63

281072

COTTER PIN,5/16" Dia x 3"

8шт.

64

120112

BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8, Full Thd

2шт.

65

86050279

FLANGE NUT,M10 x 1.5, Cl 10

8шт.

66

392530

NUT,M16, Cl 10

4шт.

67

636665

LOCK WASHER,43.18mm ID x 52.68mm OD x 1.57mm Thk

1шт.

68

86619907

NUT,1.6875"-18

1шт.

69

86995792

PAD,125mm W x 1270mm L

2шт.

70

84164490

COVER

1шт.

For EU Only

1шт.
