Запчасти Case IH 8010 (60.110.03[01]) - LATERAL TILT FEEDER ADAPTER - PRIOR TO PIN HAJ202001 - 7010/8010 (60) - PRODUCT FEEDING

Схема запчастей Case IH 8010 - (60.110.03[01]) - LATERAL TILT FEEDER ADAPTER - PRIOR TO PIN HAJ202001 - 7010/8010 (60) - PRODUCT FEEDING
16
31
12
26
34
18
17
7
27
25
16
9
14
11
7
33
29
16
10
5
3
16
13
15
14
9
24
21
20
4
16
16
30
8
8
18
23
10
60.110.02(01)
32
26
2
26
23
16
18
1
19
23
35
9
19
11
16
17
27
6
22

Артикул

Название

Примечание

Количество

1

87532606

ADAPTER

Includes: Ref 35

1шт.

For NA Only

1шт.

1

87532607

ADAPTER

Includes: Ref 35

1шт.

For EU Only

1шт.

2

87105744

SEAL KIT

Ref 6, Cylinder Repair

1шт.

3

86995541

PLASTIC

Front

1шт.

4

86995542

THRUST WASHER,77.5mm ID x 101.6mm OD x 7.8mm Thk

Center, Front

1шт.

5

87283209

RETAINING PLATE

Center, 3 Holes

1шт.

6

87282645

CYLINDER,Double Acting, 28mm Rod, 140mm Stroke

Lateral Tilt Feeder Adapter

1шт.

For NA Only

1шт.

6

87282646

CYLINDER,Double Acting, 25mm Rod, 84mm Stroke

Lateral Tilt Feeder Adapter

1шт.

For EU Only

1шт.

7

832-46408

NUT,M8 x 1.25, Cl 8

2шт.

8

84036080

BOLT,Hex, M16 x 110mm, Cl 10.9

2шт.

9

87312143

PIN,14mm OD x 68.5mm L

3шт.

10

87312141

PLATE

2шт.

11

913347

WASHER,M17 x 56mm OD x 11mm Thk

2шт.

12

87107105

U-BRACKET

1шт.

13

87001364

BRACKET

1шт.

14

120104

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

2шт.

15

86995566

DEFLECTOR

Front

1шт.

16

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

1шт.

17

9706690

NUT,M8 x 1.25, Cl 8

4шт.

18

86511841

BOLT,Flng, M8 x 1.25 x 16mm, Full Thd, Cl 8.8

4шт.

19

87107672

SPACER,20.64mm ID x 30.16mm OD x 42mm L

2шт.

20

84019930

CLEVIS PIN,6mm OD x 20mm L

1шт.

21

86523849

COTTER PIN,1/16" x 3/4"

1шт.

22

84155101

SHEET

Shield, Top

1шт.

23

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

1шт.

24

9828248

BOLT,Hex, M16 x 2 x 60mm, Cl 10.9, Full Thd

2шт.

25

87283220

LINKAGE

1шт.

26

86625266

WASHER,17.5mm ID x 30mm OD x 4mm Thk

7шт.

27

86512555

NUT,M16 x 2, Cl 10

2шт.

28

140041

WASHER,M8 x 28mm OD x 3mm Thk

1шт.

29

87283864

SENSOR

Angle

1шт.

30

87105024

ARM

1шт.

31

9824326

WASHER,5.3mm ID x 10mm OD x 1mm Thk

2шт.

32

86502967

SCREW,Phillips Drive, Pan HD, M5 x 30mm, Cl 4.8

2шт.

33

87105683

CAP

1шт.

34

86585703

SCREW,Phillips Drive, Pan HD, M8 x 20mm, Cl 4.8

4шт.

35

86996879

DECAL

English

2шт.

For NA Only

1шт.

35

87612725

DECAL

French/Spanish

2шт.

For NA Only

1шт.

35

87413244

DECAL

2шт.

For EU Only

1шт.

Выбрано товаров: 46
