Запчасти Case IH 7240 (55.404.AQ[02]) - VAR - 722810 - WORKING LIGHT, HEADLIGHT (55) - ELECTRICAL SYSTEMS
![Схема запчастей Case IH 7240 - (55.404.AQ[02]) - VAR - 722810 - WORKING LIGHT, HEADLIGHT (55) - ELECTRICAL SYSTEMS](https://partsell.ru/storage/images/caseih/5300826.png)
55.510.ah
7
7
2
1
3
3
55.510.ah
5
3
3
1
90.150.bg 02
4
5
6
55.510.ah
55.510.ah
7
6
7
90.150.bg 02
55.510.ah
4
90.150.bg 02
55.510.ah
7
7
55.510.ah
2
№
Артикул
Название
Примечание
Количество
1
47426256
WORK LAMP,HID, 12V, 35W, Clear
Integrated HID Oval Flood, Incl 5 - 6
2шт.
2
47430979
HEADLAMP,Halogen, 12V, 65W, Clear
Integrated Oval, Incl 7
2шт.
3
47430977
WORK LAMP
Integrated Oval Flood, Incl 7
4шт.
4
87284035
FASTENER,25.4mm W x 76mm OAL
Dual Locking Strip
2шт.
5
84579603
LAMP
12V, HID Ballast
2шт.
6
87722023
BULB,HID, 85V, 35W
2шт.
Выбрано товаров: 7
