Запчасти Case IH 7240 (66.331.AK[04]) - VAR - 425292 - THRESHING CYLINDER, ROTOR (66) - THRESHING

1

47825925

ROTOR

Large Tube, 76 Element, Grain, W/ Separator Bars, Incl 2 - 20

1шт.

2

87378268

AUGER FLIGHT

Inlet

2шт.

3

87394282

PLOW BOLT,M16 x 55mm, Cl 10.9

14шт.

4

9843611

BOLT,Hex, M16 x 2.0 x 55mm, Cl 10.9

2шт.

5

86512380

FLANGE NUT,M16

16шт.

6

47806899

PLATE

Wear

2шт.

7

86981487

BOLT,Flange, M12 x 35mm, Full, Cl 10.9 DOR

78шт.

8

87314103

PLOW BOLT,M12 x 1.75 x 40mm, Cl 10.9

4шт.

9

87315598

SHIELD

Nut

4шт.

10

412672

NUT,Hex, M12 x 1.75, Cl 10

6шт.

11

86625255

WASHER,13.3mm ID x 24.5mm OD x 3mm Thk

2шт.

12

1327676C1

BAR

Helical Kicker

2шт.

13

84164540

RASP BAR

W/O Spike

56шт.

14

278820A5

RASP BAR

W/ Spike, Extended Wear

8шт.

15

1318976C2

BAR,Straight Seperator

4шт.

16

87697368

PLASTIC PLUG

Dust Cover

1шт.

17

84222993

SPLINED COUPLING,12T

Rotor Drive

1шт.

18

86625266

WASHER,17.5mm ID x 30mm OD x 4mm Thk

8шт.

19

86577946

BOLT,Hex, M16 x 80mm x 10.9

8шт.

20

86512380

FLANGE NUT,M16

8шт.

21

87744743

COVER ASSY

Cone

1шт.

22

87323577

RING

Reluctor Wheel, Rotor Speed

1шт.

23

87284474

SHIM,51.18mm ID x 59.7mm OD x 1mm Thk

1шт.

24

87281633

SPACER,50.88mm ID x 66.68mm OD x 44mm L

1шт.

25

87107260

SUPPORT

Lube Hose

1шт.

26

87107259

HOSE,3.02mm ID x 737mm L

Lube

1шт.

27

87414

LUBE NIPPLE,1/4" - 28

1шт.

28

86981489

BOLT,Hex, M16 x 70mm, Cl 10.9

1шт.

29

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

4шт.

30

134814

NUT,11/16"

1шт.

31

9706690

NUT,M8 x 1.25, Cl 8

4шт.

32

86998693

WASHER,17.8mm ID x 76.2mm OD x 9.5mm Thk

1шт.

33

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

4шт.
