Запчасти Case IH 7230 (80.150.BF[01]) - VAR - 425252056, 425252066, 425373006, 425373016 - COVER, GRAIN TANK (80) - CROP STORAGE/UNLOADING

Схема запчастей Case IH 7230 - (80.150.BF[01]) - VAR - 425252056, 425252066, 425373006, 425373016 - COVER, GRAIN TANK (80) - CROP STORAGE/UNLOADING
17
37
44
33
5
49
20
38
44
1
19
3
1
43
30
46
28
20
53
50
46
12
10
14
8
36
36
32
21
41
18
50
48
41
46
15
26
52
34
11
35
25
24
55
3
41
37
45
11
32
8
27
2
18
34
24
32
31
15
80.150.bf 02
37
23
13
39
32
26
32
37
46
47
3
22
16
36
41
26
53
15
46
51
35
80.150.bf 02
5
40
42
55
9
54
8
34
52
34
14
48
29
3
56
7
35
26
42
6
51
8
28
4

Артикул

Название

Примечание

Количество

1

84399508

EXTENSION

Cover, Front/Rear, - VAR - 425252056, 425373006

2шт.

1

84399505

EXTENSION

Cover, Front/Rear, - VAR - 425252066, 425373016

2шт.

2

84510294

HANDLE

Grab, Rear

1шт.

3

130004

COTTER PIN,2.9mm OD x 31.4mm OAL

12шт.

4

84152697

UPPER LINK,17.46mm ID x 423mm L

Cover

2шт.

5

9617869

BUMPER,28.4mm W x 31.8mm L x 4.8mm Thk

Rubber

4шт.

6

84387538

COVER ASSY

Grain Tank, LH, Incl 55, 56

1шт.

7

84276253

COVER

Grain Tank, RH, Incl 55

1шт.

8

86975520

SHEET

Corner, Cover, - VAR - 425252056, 425373006

4шт.

8

86975734

SHEET

Corner, Cover, - VAR - 425252066, 425373016

4шт.

9

84510307

HALF-HINGE

Front, LH, Incl 55

1шт.

10

84355676

BRACKET,1134mm L

Seal

2шт.

11

84174215

HINGE

Cover, Rear

2шт.

12

84393348

STEP

Grain Tank, Upper

1шт.

13

84395879

STEP

Grain Tank, Middle

1шт.

14

87552212

HINGE

Hinge, Front

2шт.

15

86975516

ANGLE

Securing Strip, - VAR - 425252056, 425373006

4шт.

15

86975514

ANGLE

Securing Strip, - VAR - 425252066, 425373016

4шт.

16

86975897

BRACKET

Camera Mount

1шт.

17

87698833

BOLT,M8 x 33.1mm, Cl 10.9

5шт.

18

87491039

BRACKET

Rear Cover Open Linkage

2шт.

19

84187744

HINGE

Front, RH, Incl 55

1шт.

20

87547587

LOCK NUT,Hex, M10 x 1.5, Cl 10

4шт.

21

84403643

STRIP,1043.8mm L

Seal, RH

1шт.

22

84187736

BRACKET

Cover Stop, RH

1шт.

23

84403645

SEALING STRIP,1220mm L

Seal, LH

1шт.

24

84359872

ANCHOR

Cover Cable

2шт.

25

86975528

BRACKET

Front Grain Tank Level Sensor Mount, - VAR - 425252056, 425373006

1шт.

25

86975526

BRACKET

Front Grain Tank Level Sensor Mount, - VAR - 425252066, 425373016

1шт.

26

84194824

ANGLE

Upper Stop Anchor

4шт.

27

87682391

CARRIAGE BOLT,M10 x 1.5 x 25mm, Cl 10.9

3шт.

28

84182839

SCREW,M10 x 1.5 x 66.70mm, Heat Treated Steel

4шт.

29

362528

CLEVIS PIN,M16 x 55mm OAL

4шт.

30

86610200

THREADED INSERT,M8 x 1.25

16шт.

31

87682392

CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 10.9

6шт.

32

86975890

SCREW,Torx, Pan HD, M8 x 1.25 x 20mm, Cl 8.8

36шт.

33

87348842

SPACER,13.5mm ID x 19.18mm OD x 13.2mm L

8шт.

34

84165687

ANGLE

Cover Support, - VAR - 425252056, 425373006

4шт.

34

87491037

ANGLE

Cover Support, - VAR - 425252066, 425373016

4шт.

35

87613264

WASHER,0.53" ID x 2" OD x 0.12" Thk

0.531" ID x 2.0" OD x 0.12" W

8шт.

36

87698836

BOLT,M10 x 25mm, Full Thd, Cl 10.9

27шт.

37

84180932

CABLE RETAINER,453mm L

Cover Retention, 681.8mm OAL

4шт.

38

84187730

BRACKET, SUPPORTING

Stop Anchor, Rear, RH

1шт.

39

84393346

STEP

Grain Tank, Lower

1шт.

40

87021006

BOLT,M10 x 26.4mm, Cl 10.9

12шт.

41

87698835

FLANGE BOLT,M10 x 20mm, Full Thd, Cl 10.9

18шт.

42

87705315

DOOR SEAL

Cut From Bulk, 2286mm OAL

2шт.

43

84391053

SHEET

Extension Plug

2шт.

44

84326991

PLATE

Seal

4шт.

45

84432904

DECAL

No Step

1шт.

46

87656137

BOLT,Flange Hex, M8 x 20mm, Cl 10.9

36шт.

47

87343550

FLANGE BOLT,Hex, M12 x 25mm

2шт.

48

86507066

FLANGE NUT,M8 x 1.25, Cl 10

28шт.

49

84385052

SHEET

Cover Seal, - VAR - 425252056, 425373006

1шт.

49

84385050

SHEET

Cover Seal, - VAR - 425252066, 425373016

1шт.

50

86050279

FLANGE NUT,M10 x 1.5, Cl 10

28шт.

51

87682390

CARRIAGE BOLT,M10 x 1.5 x 20mm, Cl 10.9

6шт.

52

87698847

FLANGE BOLT,M12 x 90mm, Cl 10.9

4шт.

53

87681209

FLANGE NUT,Hex, M12 x 1.75, Cl 10

4шт.

54

87682383

CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 10.9

5шт.

55

87556665

BEARING,31.773mm ID x 35.7mm OD x 25.4mm Thk

4шт.

56

87556072

NUT,Flng, 11.8mm OD x 19.8mm L

2шт.

Выбрано товаров: 62
