Запчасти Case IH 7230 (74.130.AH[01]) - FAN HOUSING, LOWER, BSN YDG222004 (74) - CLEANING

Схема запчастей Case IH 7230 - (74.130.AH[01]) - FAN HOUSING, LOWER, BSN YDG222004 (74) - CLEANING
12
18
8
5
7
10
10
9
5
4
19
19
19
11
14
20
1
19
2
16
21
14
6
13
18
7
5
9
15
20
8
17
15
7
3
13

Артикул

Название

Примечание

Количество

1

84335319

FAN HOUSING

Cleaning

1шт.

2

87361668

SEAL

Upper Fan, 90mm W x 1570mm OAL x 3.05mm Thk

1шт.

3

84462407

SEAL PROTECTION

Upper Fan, 110mm W x 1577mm OAL x3.05mm Thk

1шт.

4

84462409

SEAL PROTECTION

Lower Secondary, 105mm W x 1571mm OAL x 0.91mm Thk

1шт.

5

747558

STRIP

Securing, 20mm W x 1515mm OAL

3шт.

6

84818312

SEAL

Lower Fan, 70mm W x 1577mm OAL x 3mm Thk

1шт.

7

445395

RIVET,Pop, 4.8mm OD x 18.1mm L

30шт.

8

84071827

CANVAS

Fan, Side, 24mm W x 191mm OAL x 1.3mm Thk

2шт.

9

140182

WASHER,5.5mm ID x 18mm OD x 2mm Thk

6шт.

10

445394

RIVET,Pop, 3/16" x 1/2" OAL

6шт.

11

87109364

DEFLECTOR

RH

1шт.

12

87109363

DEFLECTOR

LH

1шт.

13

9804256

BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8

4шт.

14

322357

BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk

4шт.

15

9804276

FLANGE NUT,Hex, M6 x 1, Cl 8

4шт.

16

87541857

SUPPORT

Fan Housing, LH

1шт.

17

87541859

SUPPORT

Fan Housing, RH

1шт.

18

86619060

CARRIAGE BOLT,M8 x 1.25 x 16mm, Cl 8.8

4шт.

19

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

4шт.

20

9706690

NUT,M8 x 1.25, Cl 8

4шт.

21

84407899

FAN

Incl 1 - 20

1шт.

Выбрано товаров: 21
