Запчасти Case IH 7230 (60.110.AA[03]) - VAR - 425070 - ADAPTER, FEEDER, HILLCO (60) - PRODUCT FEEDING

1

87283864

SENSOR

Lateral Tilt Position

1шт.

2

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

2шт.

3

120103

BOLT,M8 x 1.25 x 16mm, Cl 8.8

2шт.

4

86981478

CARRIAGE BOLT,M20 x 70.9mm, Cl 10.9

12шт.

5

86592703

WASHER,21mm ID x 50mm OD x 6mm Thk

12шт.

6

86512499

FLANGE NUT,M20 x 2.5, Cl 10

12шт.

7

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

2шт.

8

87105683

CAP

Protection

1шт.

9

84164528

SHIELD

Feeder, Top

1шт.

10

86629542

NUT,M8 x 1.25, Cl 8.8

2шт.

11

84440967

DRIVE SHAFT

Axle Extension, RH

1шт.

12

84440974

DRIVE SHAFT

Axle Extension, LH

1шт.

13

84314118

LEVER

Header Latch

1шт.

14

87367550

FLANGE BOLT,Hex, M22 x 1.5 x 95mm, Cl 12.9

10шт.
