Запчасти Case IH 7230 (88.080.10) - DIA KIT: UNLOADING AUGER EXTENSION, 0.9 M (3 FT), STANDARD CAPACITY (88) - ACCESSORIES

Схема запчастей Case IH 7230 - (88.080.10) - DIA KIT: UNLOADING AUGER EXTENSION, 0.9 M (3 FT), STANDARD CAPACITY (88) - ACCESSORIES
19
8
4
23
15
3
80.180.01
9
7
20
21
13
18
1
17
12
14
16
10
22
5
80.180.05
6
11
8
17
2

Артикул

Название

Примечание

Количество

1

87575223

AUGER

Standard & Perforated

1шт.

1

87657822

AUGER

Extended Wear

1шт.

2

87552536

TUBE,412.6 mm OD x 914.4 mm L

Unloading Auger Extension; Standard & Perforated, Red

1шт.

2

87470153

TUBE,349.6 mm ID x 412.6 mm OD x 914.4 mm L

Unloading Auger Extension; Extended Wear, Red

1шт.

3

87552541

COVER

Red

1шт.

4

84072623

SUPPORT

1шт.

5

86620026

FLANGED BEARING

2шт.

6

87605590

BEARING ASSY,35mm ID x 72mm OD x 19mm W

1шт.

6

87016482

SET SCREW,M10 x 10mm

Not Shown

1шт.

7

87011705

HUB,21T

1шт.

8

370004

SNAP RING,M35 x 1.5mm Thk, External

2шт.

9

9706685

NUT,M12 x 1.75, Cl 8

19шт.

10

43140

BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8

3шт.

11

300388

BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8

2шт.

12

300389

BOLT,M12 x 1.75 x 35mm, Cl 8.8

19шт.

13

86507486

CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8

2шт.

14

9706690

NUT,M8 x 1.25, Cl 8

2шт.

15

140046

BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk

2шт.

16

84072793

WASHER,35.5mm ID x 58mm OD x 5mm Thk

1шт.

17

394630

WASHER,13mm ID x 28mm OD x 4mm Thk

38шт.

18

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

2шт.

19

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

3шт.

20

86590413

BASE,15.87mm W x 22.22mm OAL x 9.9mm Thk

3шт.

21

445394

RIVET,Pop, 3/16" x 1/2" OAL

3шт.

22

86566989

CABLE TIE,208mm L

45 x 4.8

3шт.

23

87471942

AUGER

Extension Assy, Standard & Perforated, Red; Incl Refs 1 Thru 21, As Indicated

1шт.

23

87471943

AUGER

Extension Assy, Exended Wear, Red; Incl Refs 1 Thru 21, As Indicated

1шт.

Выбрано товаров: 27
