(88.080.02) - DIA KIT: FLIGHTING ASSY, CLEAN GRAIN ELEVATOR

Запчасти Case IH 7230 (88.080.02) - DIA KIT: FLIGHTING ASSY, CLEAN GRAIN ELEVATOR (88) - ACCESSORIES

Схема запчастей Case IH 7230 - (88.080.02) - DIA KIT: FLIGHTING ASSY, CLEAN GRAIN ELEVATOR (88) - ACCESSORIES
3
3
5
2
1
4
5
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84083472

KIT

Flight Assy, Scraper Assy For Clean Grain Elevator (See Page 80.101.34)

1шт.

2

87283161

BLADE

2шт.

3

43128

BOLT,M8 x 1.25 x 30mm, Cl 8.8

4шт.

4

86629542

NUT,M8 x 1.25, Cl 8.8

4шт.

5

NLS

NO LONGER SERVICED

No Longer Used, Part Of Ref 3

1шт.

1

84083472

KIT

Flight Assy, Scraper Assy For Clean Grain Elevator (See Page 80.101.34)

1шт.

2

87283161

BLADE

2шт.

3

43128

BOLT,M8 x 1.25 x 30mm, Cl 8.8

4шт.

4

86629542

NUT,M8 x 1.25, Cl 8.8

4шт.

5

NLS

NO LONGER SERVICED

No Longer Used, Part Of Ref 3

1шт.

Выбрано товаров: 10
