Запчасти Case IH 7230 (74.110.03) - GRAIN PAN DRIVE (74) - CLEANING

1

86629542

NUT,M8 x 1.25, Cl 8.8

8шт.

2

87486176

ARM

Incl Ref 4, 87391745

2шт.

3

320033

BEARING HALF

8шт.

4

87391745

RUBBER BUSHING,19mm ID x 42.7mm OD x 40mm L

4шт.

5

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

16шт.

6

120062

BOLT,Hex, M8 x 70mm, Cl 8.8

8шт.
