Запчасти Case IH 7140 (80.150.BG[03]) - VAR - 425466 - GRAIN BIN EXTENSION (80) - CROP STORAGE/UNLOADING

Схема запчастей Case IH 7140 - (80.150.BG[03]) - VAR - 425466 - GRAIN BIN EXTENSION (80) - CROP STORAGE/UNLOADING
20
3
28
37
43
5
1
27
10
25
11
41
22
9
7
31
6
33
36
15
40
80.150.bg 04
16
44
32
80.150.bg 04
19
26
18
12
21
38
8
1
30
24
3
17
42
14
2
13
28
27
29
39
3
34
24
35
4
23
20
45
80.150.bg 04

Артикул

Название

Примечание

Количество

1

87606500

HINGE

LH

2шт.

2

87474228

HINGE

RH

2шт.

3

86507066

FLANGE NUT,M8 x 1.25, Cl 10

10шт.

4

86511315

WASHER,8.4mm ID x 16mm OD x 1.8mm Thk

2шт.

5

84367834

EXTENSION

LH, 32"

1шт.

6

84367830

EXTENSION

RH, 32"

1шт.

7

87726836

CANVAS,938.3mm W x 1345.5mm L

Corner Extension, 32"

4шт.

8

87735041

ANGLE

Extension, 32"

8шт.

9

86995792

PAD,125mm W x 1270mm L

Anti-Slip Strip

4шт.

10

87107781

BRACKET

Panel Support

1шт.

11

87608564

BRACKET

Latch, Extension Panel

1шт.

12

87553944

ROD

Prop

2шт.

13

87106279

PIN,6.4mm OD

Klik, Quick Disconnect

2шт.

14

86976901

CLIP

Prop Rod

2шт.

15

87603123

SUPPORT

Tank Support

1шт.

16

84300515

ACCESS COVER

Actuator Access

1шт.

17

87614100

COVER

Tank Extension

1шт.

18

84555626

PLATE

Tank Support

1шт.

19

120117

BOLT,Hex, M10 x 1.5 x 110mm, Cl 8.8, Full Thd

1шт.

20

378244

WASHER,10.5mm ID x 24mm OD x 2mm Thk

2шт.

21

86050279

FLANGE NUT,M10 x 1.5, Cl 10

28шт.

22

140046

BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk

3шт.

23

86508622

BOLT,Hex, M12 x 1.75 x 100mm, Cl 10.9

1шт.

24

87656137

BOLT,Flange Hex, M8 x 20mm, Cl 10.9

7шт.

25

86619801

FLANGE NUT,M8 x 1.25, Cl 8

1шт.

26

87030508

BOLT,Hvy Hex, M12 x 30mm, Full Thd, Cl 10.9

10шт.

27

87698835

FLANGE BOLT,M10 x 20mm, Full Thd, Cl 10.9

13шт.

28

87032825

BOLT,Hvy Hex, M12 x 100mm, Cl 10.9

10шт.

29

86512497

FLANGE NUT,M12 x 1.75, Cl 10

15шт.

30

87681209

FLANGE NUT,Hex, M12 x 1.75, Cl 10

8шт.

31

86975890

SCREW,Torx, Pan HD, M8 x 1.25 x 20mm, Cl 8.8

66шт.

32

120041

CARRIAGE BOLT,M10 x 20mm, Cl 8.8

6шт.

33

86978772

FLANGE BOLT,Hex, M16 x 40mm, Cl 10.9, Full Thd

1шт.

34

86512498

FLANGE NUT,M16 x 2, Cl 10

1шт.

35

86599359

EYEBOLT

M10 x 75mm

1шт.

36

87698841

BOLT,Hex, M10 x 70mm, Cl 10.9

Flange, M10 x 70mm, 10.9

1шт.

37

86975571

SPRING,Extension, 72.4mm OD x 356mm L

356mm

1шт.

38

86705429

BOLT,M10 x 34.2mm OAL, Full Thd, Cl 10.9

Flange, M10 x 25mm, Full Thread, 10.9

10шт.

39

87656571

ROD

Latch, Bubbler Auger

1шт.

40

87571909

ASSEMBLY

Handle, Bubbler Latch

1шт.

41

87571967

BUSHING

Latch, Bubble Auger

1шт.

42

9706693

BOLT,M12 x 60mm, Cl 8.8

1шт.

43

140048

BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk

2шт.

44

80754

COTTER PIN,3/16" OD x 1-1/2" OAL

2шт.

45

100020

NUT,M16 x 2.0, Cl 8

4шт.

Выбрано товаров: 45
