Запчасти Case IH 7140 (73.210.AX[05]) - CHOPPING UNIT GEARBOX ASSY W/ PULLEY (73) - RESIDUE HANDLING

Схема запчастей Case IH 7140 - (73.210.AX[05]) - CHOPPING UNIT GEARBOX ASSY W/ PULLEY (73) - RESIDUE HANDLING
26
13
27
2
25
30
20
28
19
22
12
4
17
10
18
16
9
23
11
3
73.210.ax 06
7
8
5
15
24
21
29
1
14
6

Артикул

Название

Примечание

Количество

1

87629040

WASHER,1.34" ID x 2" OD x 0.12" Thk

2шт.

2

87745589

SPACER

Chopper Drive Pulley

1шт.

3

87735266

PULLEY,356mm OD

Chopper Drive

1шт.

4

87609670

HUB

Stationary, Rotor Drive

1шт.

5

87602134

PULLEY

Fixed, Rotor Drive

1шт.

6

426-832

BOLT,Hex, 1/2" - 13 x 2", Gr 8

6шт.

7

492-21050

LOCK WASHER,1/2"

6шт.

8

429-108

NUT,1/2"-13, G8

6шт.

9

87602135

PULLEY

Variable, Rotor Drive

1шт.

10

219-86

LUBE NIPPLE,1/8" NPTF

1шт.

11

238-5230

O-RING,0.139" Thk x 2.484" ID, -230, Cl 5, 75 Duro

2шт.

12

87307506

BALL BEARING,82.54mm ID x 132.06mm OD x 22.86mm W

2шт.

13

87602136

PULLEY

Female, Variator Sleeve

1шт.

14

87602138

FLEXIBLE COUPLING

Universal Joint

1шт.

15

413-12176

BOLT,3/4"-10 x 11", Gr 5

1шт.

16

87307512

SLEEVE

Male, Variator Pulley

1шт.

17

425-1412

JAM NUT,Jam, 3/4"-10, G5

2шт.

18

87313981

WASHER,1.66" ID x 2.5" OD x 0.06" Thk

8шт.

19

87677098

PULLEY ASSY.

Hub, Driven

1шт.

20

87301675

WASHER,1.38" ID x 2.5" OD x 0.25" Thk

1шт.

21

231-41120

NUT,1 1/4"-7, GB

1шт.

22

496-21106

WASHER,1 1/16" x 2" x .209", HDN

1шт.

23

232-41316

NUT,1"-8, GC

1шт.

24

87613300

WASHER,0.94" ID x 1.75" OD x 0.18" Thk

1шт.

25

425-1314

SLOTTED NUT,7/8"-14, G5

1шт.

26

432-828

COTTER PIN,1/8" x 1 3/4"

1шт.

27

87677105

PULLEY ASSY.

Driven, 4HC

1шт.

28

86639326

WASHER,17.3mm ID x 34.5mm OD x 5mm Thk

5шт.

29

87016618

LOCK WASHER,M16

5шт.

30

412398

BOLT,Hex, M16 x 2 x 50mm, Cl 10.9, Full Thd

5шт.

Выбрано товаров: 30
