Запчасти Case IH 7130 (10.206.10) - FUEL WATER SEPARATOR INSTALLATION (10) - ENGINE

84566375

SERVICE KIT

DIA, Fuel Water Seperator, Includes Ref 1-14

1шт.

1

84206790

BRACKET

1шт.

2

496-81023

WASHER

2шт.

3

87734479

SEPARATOR

1шт.

4

201-152

HYD CONNECTOR,13/16"-16 ORFS

1шт.

5

87643583

HYD CONNECTOR,5/8" ORFS x M22 x 1.5 ORFS

1шт.

6

84168350

90 ELBOW,1" - 14 ORFS x 13/16" - 16 Female Swivel

1шт.

7

84188140

90 ELBOW,1/2" Barb x M22 x 1.5 ORB

1шт.

8

84169780

HOSE ASSY.

1шт.

9

214-1706

HOSE CLAMP,#06, 0.44" - 0.78", Type M Worm

2шт.

10

86507066

FLANGE NUT,M8 x 1.25, Cl 10

4шт.

11

87698833

BOLT,M8 x 33.1mm, Cl 10.9

2шт.

12

87682383

CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 10.9

2шт.

13

84136309

FLEXIBLE HOSE,12.70mm ID x 762mm, SAE30R2

1шт.

14

86637977

CLAMP,25.4mm, Coat, 8.7mm Bolt Hole, P Type

1шт.
