Запчасти Case IH 7130 (50.200.15) - HEATER - AIR CONDITIONING - CAB AIR CONDITIONING, EXTERIOR (50) - CAB CLIMATE CONTROL

1

84221577

BRACKET

, Start Serial: Y9G002601

1шт.

1

87755364

BRACKET

Blockoff, Serial Range: -Y9G002601

1шт.

2

84334657

AIR CLEANER

Incl 3 - 5

1шт.

3

NSS

NOT SOLD SEPARAT

BODY, Air Cleaner

1шт.

4

84217229

AIR FILTER,91mm ID x 164.5mm OD x 347mm L

Cab, Fresh Air

1шт.

5

NSS

NOT SOLD SEPARAT

COVER, Air Cleaner

1шт.

6

84057675

CLAMP BRACKET

Air Cleaner

1шт.

7

87646996

INTAKE AIR HOSE,66.00 mm ID, 90.00 mm ID x 193.00 mm, SAE J20R4

Inlet

1шт.

8

9809800

DUST VALVE,1.93" ID x 2.24" OD

2шт.

9

87651811

GASKET

Air Cleaner

1шт.

10

140041

WASHER,M8 x 28mm OD x 3mm Thk

2шт.

11

43128

BOLT,M8 x 1.25 x 30mm, Cl 8.8

2шт.

12

445394

RIVET,Pop, 3/16" x 1/2" OAL

3шт.

13

214-1556

HOSE CLAMP,#56, 3.06" - 4", Type F Worm, W/ Liner

1шт.

14

214-1540

HOSE CLAMP,#40, 2.06" - 3", Type F Worm, W/ Liner

1шт.

15

84124649

COVER ASSY

Air Intake, Right Hand

1шт.

16

84124720

GASKET,5mm Thk

Cover

1шт.
