Запчасти Case IH 7130 (90.100.BJ[01]) - HOOD, ENGINE (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH 7130 - (90.100.BJ[01]) - HOOD, ENGINE (90) - PLATFORM, CAB, BODYWORK AND DECALS
3
38
5
37
38
17
39
38
38
37
37
38
32
11
41
38
41
30
40
22
90.100.bj 02
12
38
21
33
41
25
4
13
90.100.bj 02
15
90.100.bj 02
38
18
20
34
90.100.bj 02
90.100.bj 02
38
38
41
37
38
36
27
29
41
24
41
37
38
41
2
39
90.100.bj 02
26
90.100.bj 02
19
90.100.bj 02
37
14
37
37
21
35
23
38
90.100.bj 02
37
41
10
28
20
90.100.bj 02
38
30
37
39
90.100.bj 02
41
6
7
31
90.100.bj 02
16
9
27
8
41
41
38
1
23
41

Артикул

Название

Примечание

Количество

1

130003

COTTER PIN,3mm OD x 30mm OAL

3шт.

2

140040

WASHER,6.6mm ID x 22mm OD x 2mm Thk

3шт.

3

84469063

ROD

Platform

1шт.

4

158188

PLUG,19mm Hole, 28.6mm OD

1шт.

5

473443R1

COTTER PIN

Cotter, 1/4"

1шт.

6

439-1420

HEADED PIN,1/4" x 1 1/4"

1шт.

7

86511323

WASHER,10.5mm ID x 20mm OD x 2mm Thk

4шт.

8

120070

BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8

2шт.

9

100037

LOCK NUT,M10 x 1.5, Cl 8

2шт.

10

86611330

PIN,16.56mm OD

14.2mm OD x 29.24mm L

1шт.

11

87913

LOCK PIN,3.17mm OD x 31.75mm L, Slotted

1шт.

12

26538

SPRING

Compression

1шт.

13

84258220

ANGLE BAR

Cover Support

1шт.

14

448354A1

BRACKET

Hook Lock Strap

1шт.

15

442774A2

HINGE

Engine Cover

2шт.

16

86050300

FLANGE NUT,M6 x 1.0, Cl 10

6шт.

17

87675531

FLANGE BOLT,M6 x 26.6mm, Cl 10.9

6шт.

18

84254778

STRAP

Engine Cover Support

1шт.

19

87281729

BUSHING

16mm OD x 9.5mm ID x 6.35mm W

1шт.

20

140041

WASHER,M8 x 28mm OD x 3mm Thk

2шт.

21

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

2шт.

22

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

1шт.

23

9706690

NUT,M8 x 1.25, Cl 8

2шт.

24

86580795

SPACER

15.9mm OD x 9mm ID x 21.8mm L

1шт.

25

43129

BOLT,Hex, M8 x 1.25 x 40mm, LH Thd, Cl 8.8

1шт.

26

84351096

SUPPORT

Cover

1шт.

27

87033737

WASHER,9mm ID x 28mm OD x 3mm Thk

2шт.

28

84534138

SUPPORT

Deaeration Tank

1шт.

29

198828C1

GROMMET,25.4mm ID x 41.1mm OD x 26.9mm Thk

41.1mm OD x 25.4mm ID x 26.9mm L

1шт.

30

198823C1

GROMMET,9.53mm ID x 41.1mm OD x 26.9mm Thk

41.1mm OD x 9.53mm ID x 26.9mm L

2шт.

31

515-23127

CLAMP,1/2", Insul, 3/8" Bolt

1шт.

32

84522425

ANGLE

Support

1шт.

33

84295596

BRACKET

Catch, LH

1шт.

34

84295598

BRACKET

Catch, RH

1шт.

35

84522427

BRACKET

Steps

1шт.

36

84281342

HINGE

Door, Separator Drive

1шт.

37

86507066

FLANGE NUT,M8 x 1.25, Cl 10

30шт.

38

87656137

BOLT,Flange Hex, M8 x 20mm, Cl 10.9

32шт.

39

87698836

BOLT,M10 x 25mm, Full Thd, Cl 10.9

6шт.

40

86050279

FLANGE NUT,M10 x 1.5, Cl 10

2шт.

41

87681207

BOLT,M8 x 24.1mm, Cl 10.9

36шт.

Выбрано товаров: 41
