Артикул
Название
Примечание
Количество
1
87548596
RIGID PLATFORM
Red
1шт.
2
87283997
ARM
1шт.
3
87283973
LADDER
1шт.
4
87510520
LADDER
Support Includes: Decal 86622073 (WARNING: Before Operating Machine...)
1шт.
For NA Only
1шт.
4
87284036
LADDER
Support - Includes Ref 42, 43, & 44
1шт.
For EU & Latin America Only
1шт.
5
NS
NOT SERVICED
Bushing - 87109507
2шт.
6
87301185
STEP
5шт.
7
87109724
HANGER
2шт.
8
87281588
PLATE
4шт.
9
86511323
WASHER,10.5mm ID x 20mm OD x 2mm Thk
1шт.
12
120069
BOLT,M10 x 1.5 x 56.58mm OAL, Cl 8.8
10шт.
15
87281392
THRUST WASHER,59.2mm ID x 76.2mm OD x 3.17mm Thk
1шт.
16
86637951
WASHER,0.81" ID x 3" OD x 0.24" Thk
1шт.
17
87109472
SPRING,40.49mm Free Length
1шт.
18
87106596
PIN,25.4mm OD x 114mm OAL
1шт.
19
87020818
LOCK PIN,1/4" OD x 2" OAL, Slotted
1шт.
20
87108760
BUSHING,10.4mm ID x 14.4mm OD x 34mm OAL
1шт.
21
87548584
HANDLE
Includes Ref 41
1шт.
22
120070
BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8
1шт.
23
87109799
PEDAL
1шт.
24
86588450
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
2шт.
25
43117
SCREW,Hex, M6 x 1.0 x 30mm, Cl 8.8
1шт.
26
86500688
NUT,Hex, M6 x 1.0, Cl 10.9
1шт.
27
87395726
HANDRAIL
L.H., Front
1шт.
28
87109394
GRAB RAIL
1шт.
29
87107072
CHAIN LINK,44.299mm Pitch
Chain
1шт.
30
87109887
CHAIN,807.32mm L
1шт.
31
86624002
BOLT,Hex, M20 x 40mm, Cl 8.8
1шт.
32
349014A1
KNOB
1шт.
33
PL
PROCURE LOCALLY
Adhesive, Loctite
1шт.
34
87281554
PLATE
3шт.
35
86633356
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
6шт.
37
86511324
WASHER,13mm ID x 24mm OD x 2.5mm Thk
4шт.
38
9706687
BOLT,M12 x 1.75 x 30mm, Cl 8.8
4шт.
39
140046
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
4шт.
41
87109878
CAP,17.5mm ID x 25.4mm OAL
Knob
1шт.
42
84004732
CAUTION DECAL
Do Not Ride on Platform or Ladder
1шт.
43
84004731
WARNING DECAL
Read Operator's Manual Before Operating
1шт.
44
84004733
DECAL
Stop Engine Before Servicing
1шт.
45
87548607
PEDAL
Foot Release
1шт.
Выбрано товаров: 48
