Запчасти Case IH 7120 (90.102.05[04]) - ENGINE GUARD- NEW TANK FEATURES, MY2010 LAR (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

84275356

FRAME

Engine Cover

1шт.

2

84273221

TOP COVER

Cover Assy, Engine, Top Front

1шт.

3

87485688

STEP

1шт.

4

87653826

HINGE

2шт.

5

84274143

TOP COVER

Cover Assy, Engine, Top Rear

1шт.

6

84274146

CHANNEL

1шт.

7

84187234

HANDRAIL

1шт.

8

87585661

SHEET METAL

Cover

1шт.

9

87582121

SHEET METAL

Cover

1шт.

10

87584090

SHEET ASSY.

Guard WA

1шт.

11

87555594

SUPPORT ASSY.

1шт.

12

84121818

GAS STRUT

1шт.

14

84218878

DEFLECTOR

1шт.

15

87555716

CURTAIN

No Longer Used-- Remove and discard

1шт.

17

86975394

BUMPER

Bumper Rubber

2шт.

18

86611329

SPRING

1шт.

19

86611330

PIN,16.56mm OD

Jack Pin

1шт.

20

87913

LOCK PIN,3.17mm OD x 31.75mm L, Slotted

1шт.

22

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

70шт.

23

43127

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

7шт.

24

9706690

NUT,M8 x 1.25, Cl 8

19шт.

25

86580795

SPACER

1шт.

27

43128

BOLT,M8 x 1.25 x 30mm, Cl 8.8

2шт.

28

84334242

GAS STRUT

Bumper

1шт.

29

86629542

NUT,M8 x 1.25, Cl 8.8

4шт.

30

87105622

STEP

2шт.

31

86624183

WASHER,6.6mm ID x 25mm OD x 1.6mm Thk

2шт.

32

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

4шт.

33

43139

BOLT,M10 x 1.5 x 25mm, Cl 8.8

4шт.

34

86511323

WASHER,10.5mm ID x 20mm OD x 2mm Thk

7шт.

35

120070

BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8

2шт.

36

100037

LOCK NUT,M10 x 1.5, Cl 8

2шт.

37

120104

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

28шт.

38

86625199

SELF-TAP SCREW,Hex, M6 x 1 x 13mm

2шт.

39

412649

BELLEVILLE WASHER,M6 Bolt Size x 18mm OD x 1.4mm Thk

4шт.

41

86625201

SELF-TAP SCREW,M8 x 1.25 x 30mm L

2шт.

43

87824531

4шт.

47

87495324

DEFLECTOR

1шт.

48

84201531

DEFLECTOR

1шт.

49

300381

BOLT,Hex, M8 x 1.25 x 35mm, Cl 8.8

1шт.

50

86977784

BOLT,Hex, M8 x 60mm, Cl 8.8, Full Thd

1шт.

51

158188

PLUG,19mm Hole, 28.6mm OD

1шт.

52

84297330

BRACKET

Bracket, Latch, Rear Engine Cover

1шт.

53

84297331

BRACKET

Bracket Latch, Front Engine Cover

1шт.

56

120100

BOLT,M6 x 20mm, Cl 8.8

2шт.

57

8706755

NUT

2шт.
