Артикул
Название
Примечание
Количество
1
86623083
SPACER
1шт.
2
614-16050
BOLT,Hex, M16 x 2 x 50mm, Cl 8.8, Full Thd
1шт.
3
80393062
WASHER
M17
3шт.
4
89515145
BUSHING
1шт.
6
84069770
SPROCKET
25T
1шт.
7
86519909
WASHER,17mm ID x 46mm OD x 5mm Thk
1шт.
8
86582836
SPACER
2шт.
10
86588887
CLEVIS
1шт.
11
84073175
WASHER,35.1mm ID x 71.5mm OD x 5mm Thk
1шт.
12
86601493
INDICATOR
1шт.
13
337829
SPRING
Compression
1шт.
14
87364
WASHER,0.53" ID x 1.06" OD x 0.1" Thk
1шт.
15
80412126
LOCK NUT
CL 8, M12 x 1.75
1шт.
16
80170012
KEY
M10 x 8 x 50
4шт.
17
84069777
SPROCKET
38T
1шт.
17
87710883
SPROCKET
47T; See Also Refs 35 & 39
1шт.
For Use W/Extended Wear Grain Tank
1шт.
18
80310146
FLANGE
2шт.
19
86594534
SPROCKET
Idler, 25T
1шт.
20
80443898
BALL BEARING
1шт.
21
9706755
NUT,M6, Cl 8
3шт.
22
322357
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
3шт.
24
140048
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
1шт.
25
832-46408
NUT,M8 x 1.25, Cl 8
1шт.
26
84069795
SPROCKET
Driving, 25T
1шт.
29
84073176
SHEAR BOLT BUSHING
1шт.
31
34821
WASHER,17.86mm ID x 28.57mm OD x 1.52mm Thk
2шт.
32
86627639
SPROCKET,15T
Idler, 15T
1шт.
33
66553
BALL BEARING,16.13mm ID x 40mm OD x 12.12mm W
1шт.
34
9800957
WASHER,35.81mm ID x 50.8mm OD x 1.52mm Thk
(M36)
11/ARшт.
35
84069677
SPROCKET,43T
43T
1шт.
35
87710883
SPROCKET
47T; See Also Refs 17 & 39
1шт.
For Use W/Extended Wear Grain Tank
1шт.
36
84073172
WASHER,13mm ID x 60mm OD x 12mm Thk
3шт.
37
140046
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
3шт.
38
9706687
BOLT,M12 x 1.75 x 30mm, Cl 8.8
2шт.
39
86998066
CHAIN,60H, 284 Links x 19.05mm = 5410.2mm
RC 60H, 3/4"-pitch, 284 Pitches
1шт.
39
87680581
CHAIN,60H, 288 Links x 19.05mm = 5486.4mm
RC 60H, 3/4"-pitch, 288 Pitches; See Also Refs 17 & 35
1шт.
For Use W/Extended Wear Grain Tank
1шт.
40
86595264
LINK CHAIN
Connecting, RC 60 H, Cotter-pin-type
1шт.
41
86629541
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
1шт.
42
87753010
DIA KIT, HARVESTER
Grain Tank Auger Slow Down; Incl Refs 17, 35, 39 (Extended Wear), & Instructions (Unload Rate is 2.7 bu/sec After Installation)
1шт.
For Rice Harvest & Extended Wear Grain Tank
1шт.
Выбрано товаров: 49
