Артикул
Название
Примечание
Количество
1
84453963
FINAL DRIVE
Gearbox, Final Drive, 13.09/1, Standard Axle, With and W/O Diff Lock, Used On 71/81/9120 All Regions, Refer To Manuf. Tag On Final Drive To Identify If Std Or Mud
1шт.
1
84407411R
REMAN-FINAL DRIVE
8120, 9120, Both (9/08-), 7120 (9/08-2/12), All AXIAL-FLOW COMBINE, Gearbox, Final Drive, 13.09/1, Standard Axle, With and W/O Diff Lock, Reman for New PN 84453963
1шт.
1
84407411C
CORE-FINAL DRIVE
Return Number
1шт.
1
84453965
FINAL DRIVE
Gearbox, Final Drive, 13.09/1, Mud Axle, W/ Diff Lock, Used On 81/9120 EU Only, Refer To Manuf. Tag On Final Drive To Identify If Std Or Mud
1шт.
1
84407411R
REMAN-FINAL DRIVE
8120, 9120, Both (9/08-), 7120 (9/08-2/12), Both AXIAL-FLOW COMBINE, Gearbox, Final Drive, 13.09/1, Mud Axle, W/ Diff Lock, Reman for New PN 84453965
1шт.
1
84407411C
CORE-FINAL DRIVE
Return Number
1шт.
2
84448821
HOUSING
Standard
1шт.
2
84074834
HOUSING
Mud
1шт.
3
9832264
SEAL,198.3mm ID x 230mm OD x 13mm Thk
Standard
1шт.
3
84074404
SEAL,272.47mm ID x 297.87mm OD x 39mm Thk
Seal, Mud
1шт.
4
84449320
DRIVEN SHAFT
Wheel, Serial Range: -`0
1шт.
For Standard Only
1шт.
4
84449574
AXLE
Wheel, Serial Range: -`0
1шт.
With Mud Seal
1шт.
5
87327478
BOLT,Flange, M22 x 75mm, Cl 12.9
15шт.
8
84074713
SHIM,0.5mm Thk
1ARшт.
9
84074712
SHIM,130mm ID x 72.5mm OD x 0.2mm Thk
2ARшт.
10
84074711
SHIM,0.05mm Thk
2ARшт.
11
84074701
TAPERED BEARING,45mm ID x 80mm OD x 26mm W
2шт.
12
84449593
GEAR,18T
Driving, 18T
1шт.
14
220025
SEALING RING,24.3mm ID x 28.9mm OD x 2mm Thk
Washer, 28.9 OD x 24.3 ID x 2.0 Thk
2шт.
15
84074543
SET SCREW,Hex Soc, M16 x 30
3шт.
16
84819478
COVER
Inner Shell
1шт.
17
84074391
DOWEL,16mm OD x 60mm L
16 x 60, M8 Internal Thread
2шт.
18
84448749
COVER
1шт.
19
84448750
LOCKING PLATE
1шт.
20
84448751
LOCKING PLATE
1шт.
21
84818180
LOCK NUT,M90 x 2
1шт.
22
84074719
TAPERED BEARING,90mm ID x 145mm OD x 35mm W
1шт.
23
84071596
PLASTIC PLUG,M31 x 19mm
Sight, Lower, 26 mm
2шт.
23
84817215
PLUG,3/4"
Upper, Plastic, 26 mm, Socket Head
2шт.
24
84074519
MAGNETIC PLUG,M24 x 1.5, 96L
1шт.
25
84449172
SNAP RING,M92
Out, 95.4 OD x 2.5 Thk
1шт.
26
84449597
LOCKING PLATE
1шт.
27
84449598
LOCK NUT,M100 x 2
1шт.
28
84449190
TAPERED BEARING,100mm ID x 145mm OD x 24mm W
2шт.
29
84806528
GEAR,72T
72T x 33T
1шт.
30
84449173
SNAP RING,M199.5, Int.
x 3 Thk
1шт.
31
84806529
GEAR
33T
1шт.
32
84074395
SNAP RING,M123.6
130.8 OD x 2.82 Thk
1шт.
33
84449594
RETAINER
Carrier Planet
1шт.
34
84074023
SHIM,51.5mm ID x 80mm OD x 1mm Thk
6шт.
35
84074703
NEEDLE,8mm x 42mm
8 x 42
69шт.
36
84074702
PLANETARY GEAR,21T
21T
3шт.
37
84072219
PIN,50.5mm OD x 110.2mm L
100 x 50
3шт.
38
84074400
O-RING,4mm Thk x 500mm ID, 70 Duro
NBR70
2шт.
39
84074723
SPLINED RING,75T
1шт.
40
84074399
PLUG
HH, M45 x 1.5, Tapered
1шт.
41
84074720
TAPERED BEARING,140mm ID x 210mm OD x 45mm W
1шт.
42
84449197
FLANGE
Housing, Bearing
1шт.
43
814-10030
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
5шт.
45
814-10020
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd
3шт.
47
140048
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
12шт.
48
86521733
BOLT,Hex Flg, M16 x 90mm, Cl 10.9
12шт.
49
87375317
SHIM,4.6mm Thk
Adjusting
1шт.
50
87357938
SHIM,4.65mm Thk
Adjusting
1шт.
51
87357939
SHIM,4.75mm Thk
Adjusting
1шт.
52
87380319
SHIM,4.85mm Thk
Adjusting
1шт.
53
87380320
SHIM,4.9mm Thk
Adjusting
1шт.
54
87358151
SHIM KIT
Incl Refs 49 - 53
1шт.
Выбрано товаров: 65
