Запчасти Case IH 7120 (10.406.08[01]) - FAN SHROUD - 7120/7120(LA) (10) - ENGINE

1

86979986

WASHER,0.34" ID x 1.25" OD x 0.06" Thk

22шт.

2

87584335

ANGLE

Angle

2шт.

3

87284531

NUT,Rivnut, M8 x 1.25, 0.5mm - 3mm Grip Range

20шт.

4

86976968

INSERT,Rivnut, M10 x 1.5 x 19mm OD

2шт.

5

217-151

FITTING,3/8" Hose Barb x 1/4" Male NPTF

1шт.

6

87576498

SHROUD

Top

1шт.

7

87576500

SHROUD

Bottom

1шт.

8

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

26шт.

9

120104

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

30шт.

10

617215

MOLDING

L = 6' (0.15' Needed)

1шт.

11

86639313

WASHER,9mm ID x 24mm OD x 2mm Thk

6шт.

12

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

6шт.

13

43140

BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8

2шт.

14

87000778

PLUG,89mm OD

2шт.

15

86625234

DRAINCOCK/TAP SUPPLY,1/4" NPTF

1шт.

16

87306797

ADAPTER,1/4"-18 Fem NPTF x 1/4"-18 NPTF Male

1шт.

17

87735597

BUSHING

2шт.

18

412151

BOLT,M10 x 1.5 x 61.58mm, Cl 8.8

2шт.
