Запчасти Case IH 7010 (90.118.39[02]) - RAILING, PLATFORM - NA - 7010/8010 (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH 7010 - (90.118.39[02]) - RAILING, PLATFORM - NA - 7010/8010 (90) - PLATFORM, CAB, BODYWORK AND DECALS
10
15
9
7
11
10
5
12
1
9
5
10
13
2
10
5
5
3
6
8
8
7
15
14
9
7
7
4
13
10
7
11
5
7
12
90.118.38
90.115.03
90.118.38

Артикул

Название

Примечание

Количество

1

87548617

PLATFORM

150, Extension

1шт.

2

87109386

HANDRAIL

1шт.

3

87284635

HANDRAIL

L.H.

1шт.

4

87109879

KNOB

Ladder Latch

1шт.

5

86511323

WASHER,10.5mm ID x 20mm OD x 2mm Thk

18шт.

6

43138

BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8

4шт.

7

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

18шт.

8

43140

BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8

8шт.

9

43139

BOLT,M10 x 1.5 x 25mm, Cl 8.8

6шт.

10

100016

NUT,M10 x 1.5, Cl 8

18шт.

11

87510645

EYEBOLT,M6

(x 1 x 33), Campaign Item

2шт.

12

322357

BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk

Campaign Item

2шт.

13

326376A2

LINK

Campaign Item

2шт.

14

87109887

CHAIN,807.32mm L

Ladder Gate, Campaign Item

2шт.

15

87308550

NUT,M6

Dome, Campaign Item

1шт.

Выбрано товаров: 15
