Запчасти Case IH 6140 (66.110.AD) - CONCAVE SUPPORT, RH (66) - THRESHING

1

47657974

SUPPORT

Concave, RH

1шт.

2

87698846

BOLT,Hvy Hex Flg, M12 x 80mm, Cl 10.9

2шт.

3

87681209

FLANGE NUT,Hex, M12 x 1.75, Cl 10

2шт.

4

282766A1

SHAFT

Concave Anchor

1шт.

5

279086A1

SHAFT

Concave Clamp

1шт.

6

87691372

EYEBOLT

Forged

6шт.

7

47529790

SUPPORT

Strap, RH

2шт.

8

9706685

NUT,M12 x 1.75, Cl 8

12шт.

9

496-41053

WASHER,13.49mm ID x 31.75mm OD x 5.05mm Thk

2шт.
