(90.102.08[03]) - ENGINE COVER, MAIN, 5/6/7130

Запчасти Case IH 6130 (90.102.08[03]) - ENGINE COVER, MAIN, 5/6/7130 (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH 6130 - (90.102.08[03]) - ENGINE COVER, MAIN, 5/6/7130 (90) - PLATFORM, CAB, BODYWORK AND DECALS
6
3
1
home
2
5
4
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84592584

COVER

Incl Ref 2

1шт.

2

401502

ANTI-SKID STRIP

6шт.

3

158188

PLUG,19mm Hole, 28.6mm OD

2шт.

4

83952214

BALL STUD,M8 x 29.5mm OAL

2шт.

5

84292651

GAS STRUT

2шт.

6

86507066

FLANGE NUT,M8 x 1.25, Cl 10

2шт.
