Запчасти Case IH 6088 (35.500.AJ) - ROTARY SCREEN HYDRAULIC SYSTEM (35) - HYDRAULIC SYSTEMS

1

87609543

HOSE ASSY.

Rotary Screen, Pump to Tube, Incl 2

1шт.

2

238-6014

O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro

3шт.

3

87609432

TUBE,12.70 mm OD x 1715 mm L

Rotary Screen Supply

1шт.

4

87725588

TUBE ASSY.

Rotary Screen Supply

1шт.

5

109619A1

CLAMP

Hydraulic Tube

3шт.

6

87000230

PLATE

Hose Clamp

3шт.

7

84126483

SUPPORT

Tube Bundle Center

1шт.

8

201-361

ELBOW,90 Degree Elbow, 1" - 14 Male JIC x 1" - 14 Female JIC

Incl 9

1шт.

9

238-6016

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

6шт.

10

87723253

TUBE ASSY.

RAS Tube to Filter

1шт.

11

87634522

HOSE ASSY.

Seperator Clutch Cylinder, Incl 20

2шт.

12

515-23317

CLAMP,31.75mm ID, 10.3mm Bolt Hole, P Type

3шт.

13

87670761

FLANGE BOLT,M8 x 68.1mm, Cl 10.9

3шт.

14

86507066

FLANGE NUT,M8 x 1.25, Cl 10

6шт.

15

87656137

BOLT,Flange Hex, M8 x 20mm, Cl 10.9

3шт.

16

87609430

HOSE ASSY.

Vacuum Motor Return, Incl 9

1шт.

17

201-433

TEE,1"-14 ORFS x 1"-14 Sw Run

Incl 9

1шт.

18

201-161

UNION

Incl 20

1шт.

19

203-903

TUBE NUT,1"-14 ORFS

1шт.

20

238-6012

O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro

5шт.
