Запчасти Case IH 2588 (88.474.13) - KIT SIEVE LAMP (88) - ACCESSORIES

1

87308424

KIT

Incl 2 - 17

1шт.

2

6-16760

INSTRUCTION

1шт.

3

87308425

PLATE

1шт.

4

87001315

WORK LAMP,Halogen, 12V, 37.5W, Clear

1шт.

5

87353529

BRACKET

1шт.

6

86512174

BOLT,Hex Serr Flg, 3/8" - 16 x 1 1/4"

1шт.

7

247780

SERRATED NUT,Flg, USR, 3/8"-16

1шт.

8

87314912

SHIELD

1шт.

9

87308449

WASHER

2шт.

10

523292

BOLT,1/4" - 20 x 1.03" OAL

1шт.

11

86625061

NUT,1/4"-20, GB

1шт.

12

167800C1

CLIP

1шт.

13

86511920

SCREW,Phillips Drive, Pan HD, #10 - 24 x 1/2"

1шт.

14

523310

SERRATED NUT,Flng, #10 - 24, Gr 5

1шт.

15

87314913

RETAINER

1шт.

16

523291

BOLT,Hex Serr Flg, 1/4" - 20 x 1/2"

2шт.

17

523282

SERRATED NUT,Flg, USR, 1/4"-20

2шт.
