Артикул
Название
Примечание
Количество
1
370220A1
EXTENSION
6", Drive Axle, Serial Range: -HAJ301909
2шт.
1
87623012
EXTENSION
6", Drive Axle, Start Serial: HAJ301909
2шт.
1
240851A1
EXTENSION
12", Drive Axle, Shown
2шт.
1
240851A2
EXTENSION
12", Drive Axle, If Used, Serial Range: -HAJ301909
2шт.
1
87589906
EXTENSION
12", Drive Axle, If Used, Start Serial: HAJ301909
2шт.
1
356418A1
AXLE
Extension Assy, 13", Drive, If Used (Not Shown), Serial Range: -HAJ301909
2шт.
1
87589907
EXTENSION
13", Drive Axle, If Used (Not Shown), Start Serial: HAJ301909
2шт.
2
135314A1
BUSHING,20.1mm ID x 21.75mm OD x 12.7mm L
12шт.
3
NSS
NOT SOLD SEPARAT
Shaft, Axle, With Extensions
1шт.
4
827-20070
BOLT,Hex, M20 x 2.5 x 70mm, Cl 10.9
1шт.
4
627-20060
BOLT,Hex, M20 x 2.5 x 60mm, Cl 10.9, Full Thd
1шт.
5
137339A2
WASHER,21mm ID x 33.5mm OD x 4mm Thk
22 x 34 x 3.4 mm
1шт.
6
832-41320
NUT,M20 x 2.5, Cl 10
1шт.
7
136416A5
AXLE
1шт.
8
335400A1
REINFORCEMENT
With 12" Axle Extension, Serial Range: -HAJ301909
1шт.
Used With P/N 240851A2
1шт.
8
87628998
ROD
With 12" Axle Extension, Start Serial: HAJ301909
1шт.
Used With P/N 87589906
1шт.
8
356459A1
REINFORCEMENT
With 13" Axle Extension, Serial Range: -HAJ301909
1шт.
Used With P/N 356418A1
1шт.
8
87633280
REINFORCEMENT
With 13" Axle Extension, Start Serial: HAJ301909
1шт.
Used With P/N 87589907
1шт.
8
370221A2
REINFORCEMENT
With 6" Axle Extension, Serial Range: -HAJ301909
1шт.
8
87633278
REINFORCEMENT
With 6" Axle Extension, Start Serial: HAJ301909
1шт.
9
232-41320
LOCK NUT,1 1/4"-7, GC
, Serial Range: -HAJ301909
2шт.
9
425-1020
NUT,1 1/4"-7, G5
, Serial Range: -HAJ301909
2шт.
9
87605315
NUT
, Start Serial: HAJ301909
2шт.
10
861-20060
HEX SOC SCREW,M20 x 60mm, Cl 12.9
26шт.
11
370223A1
SPACER
With 6" Axle Extension
2шт.
12
425-1020
NUT,1 1/4"-7, G5
With 6" Axle Extension
2шт.
13
232-41320
LOCK NUT,1 1/4"-7, GC
With 6" Axle extension
2шт.
14
396-31131
WASHER,1 3/8" x 2 1/2" x 1/4", HDN
With 6" Axle Extension
2шт.
87649541
REINFORCEMENT
Kit, 6" Axle Extension Rod, Serial Range: -HAJ301909
1шт.
87649542
REINFORCEMENT
Kit, 12" Axle Extension Rod, Serial Range: -HAJ301909
1шт.
87649543
REINFORCEMENT
Kit, 13" Axle Extension Rod, Serial Range: -HAJ301909
1шт.
Выбрано товаров: 35
